53290-1880
- Mfr.Part #
- 53290-1880
- Manufacturer
- Molex
- Package / Case
- Datasheet
- Download
- Description
- 2.0 BTB WAFER ASSY 18CKT WHITE
- Stock
- 34,422
- In Stock :
- 34,422
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Molex
- Product Category :
- Headers, Male Pins
- UL Flammability Code :
- 94V-0
- Mounting Style :
- Through Hole
- Mounting Type :
- BOARD
- Brand :
- Molex
- Product Status :
- Active
- Option :
- GENERAL PURPOSE
- Number of Contacts :
- 18(POS)
- Manufacturer :
- Molex
- MIL Conformance :
- No
- Application :
- Board-to-Board
- Reach Compliance Code :
- Compliant
- RoHS :
- Details
- Pitch :
- 2 mm
- Packaging :
- Tray
- Body Orientation :
- Straight
- Total Number of Contacts :
- 18
- Number of Contact Rows :
- 1
- Housing Color :
- Natural
- Current Rating :
- 1.5 A
- Gender :
- HDR
- Orientation :
- Vertical
- Type :
- Shrouded Header
- Number of Rows :
- 1 Row
- Minimum Operating Temperature :
- - 40 C
- Pbfree Code :
- yes
- DIN Conformance :
- No
- Subcategory :
- Board to Board and Mezzanine Connectors
- Voltage Rating :
- 125 V
- Housing Material :
- Polyester
- Termination Method :
- Solder
- Termination Style :
- Solder
- Product Length (mm) :
- 39(mm)
- Package :
- Box
- Product Type :
- Board to Board and Mezzanine Connectors
- Product Depth (mm) :
- 3.7(mm)
- Connector Type :
- BOARD CONNECTOR
- IEC Conformance :
- No
- Number of Positions :
- 18 Position
- Terminal Pitch :
- 2 mm
- Pitch (mm) :
- 2(mm)
- Filter Feature :
- No
- Voltage Rating Max :
- 125V
- Mounting Angle :
- Vertical
- Contact Gender :
- Male
- Operating Temp Range :
- -40C to 105C
- Mating Information :
- MULTIPLE MATING PARTS AVAILABLE
- Contact Plating :
- Tin
- Product Category :
- Board to Board and Mezzanine Connectors
- Mixed Contacts :
- No
- Contact Material :
- Brass
- JESD-609 Code :
- e3
- Maximum Operating Temperature :
- + 105 C
- Current Rating (Max) :
- 1.5/Contact(A)
- Series :
- 53290
- Contact Finish Termination :
- Tin
- Product Height (mm) :
- 6(mm)
- Termination Type :
- Solder
- Datasheets
- 53290-1880
