1792045

Manufacturer :

Phoenix Contact

Product Category :

Headers, Plugs and Sockets

Additional Feature :

PA, 94V-0

Max Supply Voltage :

250V

Plug Wire Entry :

90°

Current :

15A

Number of Contacts :

5

Mount :

Cable, Free Hanging

Connector Type :

Screw, Socket

Packaging :

Bulk

Voltage :

300V

Color :

Green

Number of Levels :

1

Material :

Polyamide

ECCN Code :

EAR99

Series :

COMBICON MVSTBR

Insulation Material :

Nylon

Safety Approval :

UL

Lead Free :

Lead Free

RoHS Status :

RoHS Compliant

Material Flammability Rating :

UL94 V-0

Feature :

Retention Latches (Wire Side)

Weight :

1.59982kg

Length :

25mm

Screw Size :

M3

Number of Decks :

1

Wire Gauge (Min) :

24 AWG

Insulation Height :

1.024 26.01mm

Pitch :

0.197 5.00mm

Approval Agency :

CB, CSA, UL, VDE, cULus

Type :

Plug, Female Sockets

Number of Rows :

1

Width :

12.6mm

Voltage - IEC :

630V

Published :

2008

Height :

26mm

Torque - Screw :

0.5-0.6 Nm (4.4-5.3 Lb-In)

Voltage - Rated :

250V

Stripping Length :

7mm

Wire Gauge (Max) :

12 AWG

Number of Ways :

5

Housing Material :

Polyamide (PA), Nylon

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Pbfree Code :

yes

Contact Plating :

Tin

Wire Gauge or Range - mm² :

0.2-2.5mm2

Gender :

FEMALE

Current Rating :

12A

Wire Gauge or Range - AWG :

12-30 AWG

Factory Lead Time :

7 Weeks

Radiation Hardening :

No

Depth :

12.6mm

Max Current Rating :

12A

Termination :

Screw

Flammability Rating :

UL94 V-0

Mounting Type :

Free Hanging (In-Line)

Termination Style :

Screw - Rising Cage Clamp

Orientation :

Straight
