V48SR15004NRFA

Manufacturer :

Delta Electronics

Product Category :

Package / Case :

8-DIP Module, 1/16 Brick

Series :

Delphi V48SR (66W)

Max Power Dissipation :

66W

RoHS Status :

ROHS3 Compliant

Min Operating Temperature :

-40°C

Mounting Type :

Through Hole

Output Voltage :

15V

Length :

33.02mm

Min Input Voltage (DC) :

36V

Factory Lead Time :

24 Weeks

Type :

Isolated Module

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Radiation Hardening :

No

Current - Output 1 :

4.4A

Diameter :

9.398mm

Voltage - Output 1 :

15V

Output Power :

66W

Size / Dimension :

1.30Lx0.90W x 0.37 H 33.0mmx22.8mmx9.5mm

Voltage - Input (Min) :

36V

Number of Outputs :

1

Voltage - Input (Max) :

75V

Packaging :

Bulk

Max Input Voltage :

75V

Max Operating Temperature :

85°C

Applications :

ITE (Commercial)

Color :

Black

Feature :

Remote On/Off, OCP, OTP, OVP, UVLO

Output Current :

4.4A

Power (Watts) :

66W

Min Input Voltage :

36V

Material :

Metal

Height :

9.398mm

Current - Output (Max) :

4.4A

Control Features :

Enable, Active Low

Max Input Voltage (DC) :

75V

Voltage - Isolation :

2.25kV

Published :

2012

Max Output Current :

4.4A

Efficiency :

90.5%

Operating Temperature :

-40°C~121°C

Width :

22.86mm

Mount :

Through Hole
