PTH03050YAST

Manufacturer :

Texas Instruments

Product Category :

Buffers, Drivers, Receivers, Transceivers

Type :

Non-Isolated PoL Module

Applications :

ITE (Commercial)

Max Power Dissipation :

10.8W

Max Output Current :

6A

Size / Dimension :

0.87Lx0.50W x 0.36 H 22.1mmx12.7mmx9.1mm

Min Output Voltage :

550mV

Base Part Number :

TH03050

Lifecycle Status :

ACTIVE (Last Updated: 5 days ago)

Control Mode :

VOLTAGE-MODE

Output Voltage :

1.8V

Number of Functions :

1

Quiescent Current :

10mA

Pin Count :

6

Protections :

OUTPUT OVER CURRENT

Series :

PTH03050Y

Feature :

Remote On/Off, OCP, UVLO

ECCN Code :

EAR99

Surface Mount :

yes

Packaging :

Tape and Reel (TR)

Approval Agency :

UL, CSA

Factory Lead Time :

6 Weeks

Pbfree Code :

yes

Voltage - Input (Max) :

3.65V

Number of Outputs :

1

Output Current :

6A

Package / Case :

6-SMD Module

Operating Temperature :

-40°C~85°C

Current - Output 1 :

6A

Lead Free :

Contains Lead

RoHS Status :

Non-RoHS Compliant

Additional Feature :

REMOTE SHUTDOWN

Number of Terminations :

6

Trim/Adjustable Output :

yes

Efficiency :

88%

Terminal Position :

Dual

Max Output Voltage :

1.8V

Mounting Type :

Surface Mount

Radiation Hardening :

No

Height :

8.5mm

Thickness :

8.25mm

Voltage - Input (Min) :

2.95V

Terminal Form :

Ball

Voltage - Output 1 :

0.55V~1.8V

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Pins :

6

Input Voltage-Nom :

3V
