PH150F110-24

Manufacturer :

TDK-Lambda, Inc.

Product Category :

Number of Outputs :

1

Size / Dimension :

3.39Lx3.27W x 0.50 H 86.0mmx83.0mmx12.7mm

Voltage - Input (Min) :

82V

Packaging :

Bulk

Applications :

ITE (Commercial)

Current - Output (Max) :

6.3A

Surface Mount :

No

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Output Voltage :

24V

Type :

Isolated Module

Trim/Adjustable Output :

yes

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

RoHS Status :

RoHS Compliant

Published :

2010

Qualification Status :

Not Qualified

JESD-30 Code :

R-XXFM-X

Control Features :

Enable, Active Low

Terminal Position :

UNSPECIFIED

Terminal Form :

UNSPECIFIED

Feature :

Remote On/Off, OCP, OVP

Input Voltage-Nom :

110V

ECCN Code :

EAR99

Pbfree Code :

No

Reach Compliance Code :

Compliant

Voltage - Output 1 :

24V

Operating Temperature :

-20°C~85°C

Package / Case :

Module

Voltage - Input (Max) :

185V

Mounting Type :

Through Hole

Power (Watts) :

150W

Voltage - Isolation :

3kV

Series :

PH-F (150W)

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Number of Functions :

1
