MPX5500DP
Or copy the link below:
- Mfr.Part #
- MPX5500DP
- Manufacturer
- NXP Semiconductors
- Package / Case
- 6-SIP Module
- Datasheet
- Download
- Description
- IC SENSOR PRESS GAUGE 75PSI RANG
- Stock
- 7,611
- In Stock ：
- 7,611
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- NXP Semiconductors
- Product Category :
- Pressure Sensors, Transducers
- Sensors/Transducers Type :
- PRESSURE SENSOR,PEIZORESISTIVE
- Port Style :
- Barbed
- Package / Case :
- 6-SIP Module
- Mounting Feature :
- THROUGH HOLE MOUNT
- Operating Pressure :
- 72.52PSI (500kPa)
- Accuracy :
- ±2.5%
- Factory Lead Time :
- 12 Weeks
- RoHS Status :
- ROHS3 Compliant
- Operating Temperature :
- -40°C~125°C
- Feature :
- Temperature Compensated
- Maximum Pressure :
- 406.11PSI (2800kPa)
- Body Height :
- 17.78mm
- Applications :
- Board Mount
- Linearity :
- 2.5 %
- Response Time :
- 1000 μs
- Published :
- 1998
- ECCN Code :
- EAR99
- Offset-Nom :
- 0.20V
- Output :
- 0.2 V ~ 4.7 V
- Port Size :
- Male - 0.19 4.93mm Tube Dual
- Body Breadth :
- 10.67 mm
- HTS Code :
- 8542.39.00.01
- Termination Style :
- PC Pin
- Pressure Type :
- Differential
- Series :
- MPX5500
- Surface Mount :
- No
- Output Type :
- Analog Voltage
- Body Length or Diameter :
- 29.46mm
- Sensitivity (mV/V) :
- 9 mV/V
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Housing :
- Plastic
- Pressure Range-Max :
- 72.51 Psi
- Voltage - Supply :
- 4.75V~5.25V
- Datasheets
- MPX5500DP
MPX5500 Series Differential Pressure Sensor Analog Voltage -40°C~125°C 72.52PSI (500kPa) Barbed ±2.5% 0.2 V ~ 4.7 V 4.75V~5.25V Temperature Compensated
MPX5500DP Overview
This transducer is included in the package 6-SIP Module for your convenience. For reliable performance, the transducers should be set to -40°C~125°C. The transducers are capable of operating with a supply voltage of 4.75V~5.25V. A transducer of this type can measure pressures up to 72.51 Psi.
MPX5500DP Features
Moisture Sensitivity Level: Not Applicable
Package / Case: 6-SIP Module
Operating Temperature: -40°C~125°C
MPX5500 series
Sensitivity (mV/V): 9 mV/V
Operating Pressure: 72.52PSI (500kPa)
MPX5500DP Applications
There are a lot of NXP USA Inc.
MPX5500DP Transducers applications.
- Mobile Phones
- Virtual Reality and Gaming Equipment
- Indoor/Outdoor Navigation (dead-reckoning, floor/elevator/step detection)
- Vertical velocity monitoring
- Leisure, Sports, and Fitness Activity Identification
- Weather Forecasting
- Hydrogen Storage
- Refrigerant pressure monitoring in HVAC/R systems
- Dry air system pressure, process controls and automation
- Dry air system monitoring
