M80-7541245

Manufacturer :

Harwin

Product Category :

Headers, Male Pins

Termination :

Solder

Flammability Rating :

UL 94 V-0

Pbfree Code :

yes

Plating Thickness :

30u inch

Housing Color :

Black

Insulation Material :

Polyphenylene Sulfide (PPS), Glass Filled

Contact Finish Termination :

Gold (Au)

Contact Resistance :

25 mΩ

Current Rating (Amps) :

2.2A per Contact

JESD-609 Code :

e4

Series :

L-Tek

Number of Positions Loaded :

All

Terminal Length :

0.177 inch

Contact Gender :

Pin (Male)

Contact Finish - Post :

-

Housing Material :

Polyamide (PA)

Row Spacing - Mating :

0.079 (2.00mm)

Connector Type :

Header

Insulator Color :

Black

Minimum Operating Temperature :

- 55 C

Additional Feature :

POLARIZED, SHROUDED

Number Of PCB Rows :

2

Termination Post Length :

4.5 mm

PCB Contact Row Spacing :

2.0066 mm

Mating Contact Pitch :

0.079 inch

Features :

-

Tradename :

Datamate

Mounting Angle :

Straight

Insulation Resistance :

1 GOhms

Mounting Option 1 :

LOCKING

IEC Conformance :

No

Current Rating :

3 A

Operating Temperature :

-55°C ~ 125°C

Mounting Type :

Through Hole

Product :

Headers

Contact Finish Thickness - Post :

-

DIN Conformance :

No

Termination Style :

Solder Pin

Style :

Board to Board or Cable

Overall Contact Length :

-

Ingress Protection :

-

Terminal Pitch :

2 mm

Row Spacing :

2 mm

PCB Contact Pattern :

RECTANGULAR

Mixed Contacts :

No

Contact Finish Thickness - Mating :

29.5µin (0.75µm)

Reference Standard :

UL

Type :

SHROUDED

Contact Material :

Phosphor Bronze

Contact Length - Mating :

-

RoHS :

Details

Housing Gender :

-

Termination Type :

Solder

Material Flammability Rating :

UL94 V-0

Contact Pattern :

RECTANGULAR

Pitch - Mating :

0.079 (2.00mm)

Rated Current (Signal) :

3 A

Mated Stacking Heights :

7.23mm, 7.85mm, 10.2mm, 13.51mm

Body Depth :

0.218 inch

Contact Length - Post :

0.177 (4.50mm)

Shrouding :

Shrouded - 4 Wall

Product Status :

Active

MIL Conformance :

No

Contact Finish - Mating :

Gold

Contact Plating :

Gold

Contact Shape :

Circular

Option :

GENERAL PURPOSE

Insulation Color :

Black

Voltage Rating :

120 V

Body Breadth :

0.234 inch

Total Number of Contacts :

12

UL Flammability Code :

94V-0

Reach Compliance Code :

Compliant

Contact Type :

-

Pitch :

2 mm

Base Product Number :

M80-754

Reliability :

COMMERCIAL

Number of Positions :

12 Position

Filter Feature :

No

Number of Rows :

2 Row

Insulation Height :

0.219 (5.56mm)

Durability :

500 Cycles

Fastening Type :

Latch Holder

Mating Contact Row Spacing :

0.079 inch

Maximum Operating Temperature :

+ 125 C

Mounting Style :

Through Hole

Contact Style :

RND PIN-SKT

Applications :

-

Package :

Tube
