LXA08B600

Manufacturer :

Power Integrations

Product Category :

Diodes - Rectifiers - Single

Number of Pins :

3

Max Operating Temperature :

150°C

Moisture Sensitivity Level (MSL) :

2 (1 Year)

Factory Lead Time :

84 Weeks

Current - Reverse Leakage @ Vr :

250μA @ 600V

Case Connection :

CATHODE

Recovery Time :

21.5 ns

Number of Phases :

1

Max Reverse Voltage (DC) :

600V

HTS Code :

8541.10.00.80

Max Surge Current :

350A

Mounting Type :

Surface Mount

Packaging :

Cut Tape (CT)

Terminal Finish :

Matte Tin (Sn)

Power Dissipation :

83W

Peak Reverse Current :

250μA

RoHS Status :

RoHS Compliant

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Number of Terminations :

2

Published :

2011

Mount :

Surface Mount

Forward Current :

8A

JESD-30 Code :

R-PSSO-G2

Diode Type :

Standard

Element Configuration :

Single

Reverse Voltage :

600V

Operating Temperature - Junction :

150°C Max

Reverse Recovery Time :

34 ns

Diode Element Material :

SILICON

Min Operating Temperature :

-55°C

Voltage - Forward (Vf) (Max) @ If :

2.94V @ 8A

Base Part Number :

LXA08B600

Max Repetitive Reverse Voltage (Vrrm) :

600V

Number of Elements :

1

JESD-609 Code :

e3

ECCN Code :

EAR99

Radiation Hardening :

No

Peak Non-Repetitive Surge Current :

350A

Output Current-Max :

8A

Package / Case :

TO-263-3, D2Pak (2 Leads + Tab), TO-263AB

Series :

Qspeed™

Average Rectified Current :

8A

Application :

EFFICIENCY

Terminal Form :

Gull wing

Pin Count :

3
