LM2676SX-5.0
Or copy the link below:
- Mfr.Part #
- LM2676SX-5.0
- Manufacturer
- National Semiconductor
- Package / Case
- TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
- Datasheet
- Download
- Description
- SWITCHING REG, VOLTAGE-MODE, 5.4
- Stock
- 26,545
- In Stock ：
- 26,545
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- National Semiconductor
- Product Category :
- Voltage Regulators - DC DC Switching Regulators
- Number of Pins :
- 7
- Output Voltage :
- 5V
- Frequency - Switching :
- 260kHz
- Moisture Sensitivity Level (MSL) :
- 3 (168 Hours)
- Number of Terminations :
- 7
- Topology :
- Buck
- Voltage - Input (Max) :
- 40V
- Terminal Finish :
- Tin/Lead (Sn/Pb)
- Mount :
- Surface Mount
- Peak Reflow Temperature (Cel) :
- 235
- Input Voltage-Nom :
- 12V
- Mounting Type :
- Surface Mount
- Synchronous Rectifier :
- No
- Height :
- 4.65mm
- Lifecycle Status :
- NRND (Last Updated: 2 days ago)
- Output Type :
- FIXED
- Control Technique :
- PULSE WIDTH MODULATION
- Voltage - Input (Min) :
- 8V
- Max Output Current :
- 3A
- Terminal Form :
- Gull wing
- Control Mode :
- VOLTAGE-MODE
- Output Configuration :
- Positive
- Analog IC - Other Type :
- SWITCHING REGULATOR
- RoHS Status :
- Non-RoHS Compliant
- Series :
- SIMPLE SWITCHER®
- Thickness :
- 4.44mm
- Operating Temperature :
- -40°C~125°C TJ
- Package / Case :
- TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
- Time@Peak Reflow Temperature-Max (s) :
- 30
- Lead Free :
- Contains Lead
- Width :
- 8.89mm
- Number of Outputs :
- 1
- Efficiency :
- 88 %
- Operating Supply Voltage :
- 40V
- Length :
- 10.1mm
- Terminal Position :
- Single
- Quiescent Current :
- 4.2mA
- ECCN Code :
- EAR99
- Packaging :
- Tape and Reel (TR)
- Function :
- Step-Down
- Base Part Number :
- LM2676
- JESD-609 Code :
- e0
- Datasheets
- LM2676SX-5.0
[Voltage Regulators - DC DC Switching Regulators National Semiconductor LM2676SX-5.0] Overview
Introducing the LM2676SX-5.0, a cutting-edge switching regulator meticulously crafted by National Semiconductor, designed to elevate performance and efficiency in power management solutions. This sophisticated device operates on a voltage-mode control mechanism, ensuring precise regulation even in the most demanding applications. With a voltage output of 5.4 volts, it caters to a diverse array of industrial and commercial needs.
Engineered with meticulous attention to detail, the LM2676SX-5.0 epitomizes reliability, versatility, and innovation, making it the preferred choice for discerning professionals seeking uncompromising quality.
LM2676SX-5.0 Features
- Advanced Switching Regulator Technology: Delivers unparalleled efficiency and stability in voltage regulation.
- Voltage-Mode Control: Ensures precise output voltage regulation, ideal for applications requiring accuracy.
- Wide Input Voltage Range: Accommodates varying input voltages, enhancing flexibility and usability.
- Overcurrent Protection: Safeguards against potential damage due to excessive currents, ensuring device longevity.
- Compact Form Factor: Designed for space-constrained environments without compromising performance.
- Efficient Heat Dissipation: Optimal thermal management ensures reliable operation even under demanding conditions.
- Robust Construction: Built to withstand harsh industrial environments, ensuring long-term reliability and durability.
LM2676SX-5.0 Applications
- Industrial Automation: Deployed in automated manufacturing processes, the LM2676SX-5.0 facilitates precise voltage regulation, ensuring consistent performance of machinery and equipment.
- Telecommunications Infrastructure: Powering critical communication systems, this regulator ensures stable voltage supply, minimizing downtime and ensuring seamless connectivity.
- Renewable Energy Systems: Integrated into solar inverters and wind turbines, the LM2676SX-5.0 facilitates efficient energy conversion, maximizing the output of renewable energy sources.
- Automotive Electronics: Enhancing the performance of automotive electronics, this regulator ensures stable voltage supply, powering essential systems and components.
Example: Integrated into robotic arms and conveyor systems to regulate voltage levels, optimizing efficiency and productivity in industrial settings.
Example: Utilized in base stations and network infrastructure to maintain uninterrupted operation, even in remote or harsh environments.
Example: Incorporated into grid-tied inverters to regulate DC voltage from solar panels, enabling seamless integration with the utility grid.
Example: Embedded in electronic control units (ECUs) and infotainment systems to regulate voltage levels, ensuring reliable operation of automotive electronics.
