K85X-BA-25P

Manufacturer :

Kycon

Product Category :

D-Sub Connector Assemblies

Empty Shell :

No

Mixed Contacts :

No

MIL Conformance :

No

DIN Conformance :

No

Connector Style :

D-Sub

Connector Type :

Plug, Male Pins

Contact Type :

Signal

Mounting Option 1 :

LOCKING

Color :

Black

Reference Standard :

UL

Flange Feature :

Housing/Shell (Unthreaded)

Total Number of Contacts :

25

Body Breadth :

0.494 inch

Insulation Resistance :

1000000000Ohm

RoHS Status :

RoHS Compliant

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Shell Size, Connector Layout :

3 DB B

Voltage - Rated :

30V

Pbfree Code :

yes

Contact Finish :

Gold

Packaging :

Tray

Contact Design :

PREASSEM CONN

Contact Resistance :

13mOhm

Feature :

Grounding Indents

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

JESD-609 Code :

e4

Contact Form :

Stamped

Insulation Material :

GLASS FILLED POLYBUTYLENE TEREPHTHALATE

Length - Termination :

0.138 inch

Contact Finish Thickness :

Flash

IEC Conformance :

No

Number of Rows :

2

Operating Temperature :

-55°C~105°C

Factory Lead Time :

20 Weeks

Contact Material :

Brass

Shell Material, Finish :

Steel, Nickel Plated

Termination :

Solder Cup

Published :

2011

Mating Contact Pitch :

0.109 inch

Gender :

Male

Reliability :

COMMERCIAL

Option :

GENERAL PURPOSE

Number of Positions :

25

Dielectric Material :

Polybutylene Terephthalate (PBT), Glass Filled

Material Flammability Rating :

UL94 V-0

Filter Feature :

No

Current Rating (Amps) :

2A

Mounting Type :

Through Hole

Shell Finish :

Tin

Dielectric Withstanding Voltage :

700VAC V

Series :

K85X
