EET-HC2W331KA

Manufacturer :

Panasonic

Product Category :

Aluminum Electrolytic Capacitors

Lifetime @ Temp :

2000 Hrs @ 105°C

Dissipation Factor :

15 %

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Max Operating Temperature :

105°C

Mounting Type :

Through Hole

Ripple Current :

1.38A

Height Seated (Max) :

1.850 47.00mm

Number of Pins :

2

Ripple Current @ Low Frequency :

1.38A @ 120Hz

Series :

TS-HC

Life (Hours) :

2000 hours

Ripple Current @ High Frequency :

1.932A @ 10kHz

ESR (Equivalent Series Resistance) :

553mOhm @ 120Hz

Min Operating Temperature :

-25°C

Radiation Hardening :

No

Published :

2005

Package / Case :

Radial, Can - Snap-In

Packaging :

Bulk

Capacitance :

330µF

Applications :

GENERAL PURPOSE

Termination :

Snap in

Length :

45mm

Voltage - Rated DC :

450V

Size / Dimension :

1.181Dia 30.00mm

Diameter :

30mm

Tolerance :

±20%

RoHS Status :

RoHS Compliant

Voltage - Rated :

450V

Lead Pitch :

10mm

Polarization :

Polar

Operating Temperature :

-25°C~105°C

Mount :

Through Hole

Height :

45mm

Test Frequency :

120Hz

Lead Spacing :

0.394 10.00mm
