DSA75-16B

Manufacturer :

Littelfuse

Product Category :

Diodes - Rectifiers - Single

Number of Phases :

1

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Base Product Number :

DSA75

RoHS Status :

ROHS3 Compliant

Capacitance @ Vr, F :

--

Number of Pins :

2

Surface Mount :

No

Terminal Position :

UPPER

Voltage - DC Reverse (Vr) (Max) :

1600V

Max Operating Temperature :

180°C

Non-rep Pk Forward Current-Max :

1400A

HTS Code :

8541.10.00.80

Packaging :

Bulk

Lead Free :

Lead Free

Output Current-Max :

110 A

Speed :

Standard Recovery >500ns, > 200mA (Io)

Case Connection :

ANODE

ECCN Code :

EAR99

Package Shape :

Round

Mounting Type :

Chassis, Stud Mount

Voltage - Forward (Vf) (Max) @ If :

1.17V @ 150A

Technology :

Avalanche

Package :

Bulk

JEDEC-95 Code :

DO-203AB

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Operating Temperature - Junction :

-40°C~180°C

Terminal Form :

Solder Lug

Supplier Device Package :

DO-203AB

Pin Count :

1

Published :

2000

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Package / Case :

DO-203AB, DO-5, Stud

JESD-30 Code :

O-MUPM-D1

Number of Terminations :

1

Product Status :

Obsolete

Manufacturer :

IXYS

Element Configuration :

Single

Current - Average Rectified (Io) :

110A

Diode Element Material :

SILICON

Number of Elements :

1

Application :

GENERAL PURPOSE

Reach Compliance Code :

Compliant

Current - Reverse Leakage @ Vr :

6mA @ 1600V

Pbfree Code :

yes

Min Operating Temperature :

-40°C

Configuration :

Single

Reverse Voltage :

1.6kV

Max Surge Current :

1.4kA

REACH SVHC :

No SVHC

Qualification Status :

Not Qualified

Mount :

Chassis, Stud

Series :

--

Diode Type :

Avalanche

Peak Non-Repetitive Surge Current :

1.5kA

Rep Pk Reverse Voltage-Max :

1600 V

Number of Terminals :

1

Max Reverse Voltage (DC) :

1.6kV

Average Rectified Current :

110A

Factory Lead Time :

6 Weeks

Peak Reverse Current :

6mA

Forward Voltage :

1.17V
