DNR120AS48-I

Manufacturer :

XP Power

Product Category :

REACH SVHC :

Unknown

Operating Temperature :

-35°C~70°C With Derating

Type :

Enclosed

Published :

2008

Moisture Sensitivity Level (MSL) :

Not Applicable

Mounting Type :

DIN Rail

Applications :

Hazardous Locations, Industrial, ITE (Commercial)

Max Voltage Rating (AC) :

264V

Current - Output 1 :

2.5A

Efficiency :

87%

Voltage - Isolation :

3kV

Feature :

Adjustable Output, DC Input Capable, Universal Input

Max Input Voltage :

264V

Package / Case :

120

Width :

63.5mm

RoHS Status :

ROHS3 Compliant

Output Current :

2.5A

Voltage - Input :

90V~132VAC 180V~264VAC

Max Input Voltage (AC) :

264V

Size / Dimension :

4.57Lx2.50W x 4.92 H 116.0mmx63.5mmx125.0mm

Output Power :

120W

Protections :

OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE

Approval Agency :

CE

Height :

142mm

Number of Outputs :

1

Output Voltage :

48V

Min Input Voltage :

90V

Max Output Power :

120W

Nominal Output Voltage :

48V

Max Output Current :

2.5A

Weight :

630g

Min Input Voltage (AC) :

90V

Max Power Dissipation :

120W

Series :

DNR (120W)

Mount :

DIN Rail

Minimum Load Required :

No

Factory Lead Time :

21 Weeks

Power Rating :

120W
