Mfr.Part #
CI0105M1VR0-NH
Manufacturer
CviLux
Package / Case
Datasheet
Download
Description
5 POS 2.00MM(.079) SINGLE ROW SM
Stock
4,890
In Stock :
4,890

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
CviLux
Product Category :
Headers, Male Pins
Series :
CI01
Insulation Height :
0.263 (6.67mm)
Base Product Number :
CI0105M1
Current Rating (Amps) :
2A
Features :
Pick and Place, Solder Retention
Applications :
-
Insulation Color :
Natural
Contact Finish Thickness - Post :
120.0µin (3.05µm)
Number of Rows :
1
Contact Finish - Post :
Tin
Contact Material :
Brass
Voltage Rating :
250VAC/DC
Product Status :
Active
Operating Temperature :
-25°C ~ 105°C
Overall Contact Length :
-
Style :
Board to Cable/Wire
Termination :
Solder
Contact Length - Mating :
0.142 (3.61mm)
Number of Positions :
5
Mounting Type :
Surface Mount
Shrouding :
Shrouded - 4 Wall
Material Flammability Rating :
UL94 V-0
Insulation Material :
Polyamide (PA6T), Nylon 6T, Halogen Free
Contact Length - Post :
-
Mated Stacking Heights :
-
Number of Positions Loaded :
All
Ingress Protection :
-
Connector Type :
Header
Contact Shape :
Square
Fastening Type :
Detent Lock
Pitch - Mating :
0.079 (2.00mm)
Contact Finish Thickness - Mating :
120.0µin (3.05µm)
Row Spacing - Mating :
-
Contact Type :
Male Pin
Contact Finish - Mating :
Tin
Package :
Tape and Reel (TR);Cut Tape (CT);
Datasheets
CI0105M1VR0-NH
Introducing Headers, Male Pins CviLux CI0105M1VR0-NH from Chip IC,where excellence meets affordability. This product stands out with its Operating Temperature:-25°C ~ 105°C, Mounting Type:Surface Mount, CI0105M1VR0-NH pinout, CI0105M1VR0-NH datasheet PDF, CI0105M1VR0-NH amp .Beyond Headers, Male Pins CviLux CI0105M1VR0-NH ,we also offer 3220-20-0100-00, 3020-26-0300-00, 3220-26-0300-00-TR, Our vast inventory has you covered. Contact us now for immediate solutions.

CviLux CI0105M1VR0-NH


CI01 Series 1-Row Header Solder Brass Surface Mount Tin Polyamide (PA6T), Nylon 6T, Halogen Free 5-Position Board to Cable/Wire 0.263 (6.67mm) Height

CI0105M1VR0-NH Overview


Packaging is in the form of Header.This device has a Surface Mount mounting type.Specifically, it is one of the products in the CI01 Series.There are a variety of possible applications for this device, including -.Devices operate at -25°C ~ 105°C operating temperatures.

CI0105M1VR0-NH Features


CI01 series


CI0105M1VR0-NH Applications


There are a lot of Cvilux
CI0105M1VR0-NH Rectangular Connectors applications.


  • Embedded systems
  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
