    AWP14-8541-T-R

    Share

    Or copy the link below:

    Mfr.Part #
    AWP14-8541-T-R
    Manufacturer
    ASSMANN WSW Components
    Package / Case
    Datasheet
    Download
    Description
    CONN SOCKET 14POS IDC TIN
    Stock
    36,266
    In Stock ：
    36,266

    Request A Quote(RFQ)

    * Fullname:
    * Company:
    * E-Mail:
      Phone:
      Comment:
    * Quantity:
    Manufacturer :
    ASSMANN WSW Components
    Product Category :
    Free Hanging, Panel Mount
    Pitch :
    0.100 2.54mm
    Dielectric Withstanding Voltage :
    500VAC V
    Connector Type :
    Socket
    Body/Shell Style :
    PLUG
    Insulation Resistance :
    1000000000Ohm
    Contact Type :
    Female Socket
    Reference Standard :
    UL
    ECCN Code :
    EAR99
    Length :
    22.8mm
    Total Number of Contacts :
    14
    Lead Free :
    Lead Free
    Operating Temperature (Min) :
    -55°C
    Contact Material :
    Brass
    Housing Color :
    Grey
    Operating Temperature (Max) :
    105°C
    Feature :
    Feed Through, Strain Relief
    HTS Code :
    8536.69.40.40
    Published :
    2006
    Cable Termination :
    IDC
    Packaging :
    Tray
    Housing Material :
    Plastic
    Wire Type :
    Ribbon Cable
    Termination Type :
    IDC
    Number of Positions :
    14
    RoHS Status :
    RoHS Compliant
    Contact Resistance :
    30mOhm
    Height :
    7mm
    Row Spacing :
    0.100 (2.54mm)
    Reliability :
    COMMERCIAL
    Number of Rows :
    2
    Mounting Type :
    Free Hanging (In-Line)
    Wire/Cable Type :
    Ribbon
    Moisture Sensitivity Level (MSL) :
    1 (Unlimited)
    Rated Current (Signal) :
    1A
    Contact Finish :
    Tin
    Width :
    7mm
    Contact Design :
    PREASSEM CONN
    Mount :
    Free Hanging
    Color :
    Gray
    Datasheets
    AWP14-8541-T-R
    Introducing Free Hanging, Panel Mount ASSMANN WSW Components AWP14-8541-T-R from Chip IC,where excellence meets affordability. This product stands out with its Mounting Type：Free Hanging (In-Line), AWP14-8541-T-R pinout, AWP14-8541-T-R datasheet PDF, AWP14-8541-T-R amp .Beyond Free Hanging, Panel Mount ASSMANN WSW Components AWP14-8541-T-R ,we also offer 3-640440-5, 04ZR-8M-P, 61201023021, Our vast inventory has you covered. Contact us now for immediate solutions.
