769-211

Manufacturer :

WAGO

Product Category :

Specialized

RoHS :

yes

Connectable conductor cross section fine-strand with cable end sleeve :

0.25 - 2.5

Material - Insulation :

Polyamide (PA66), Nylon 6/6

EU RoHS :

Compliant

Current - IEC :

32 A

Connectable conductor cross section multi-wired :

0.08 - 4

Type :

Pluggable Block

Wire Gauge or Range - AWG :

12-28 AWG

Flammability Rating :

UL94 V-0

Rated current In :

32

Package :

Box

Termination Style :

Plug Receptacles, Push In, Spring

Number of Levels :

1

Wire Gauge or Range - mm² :

0.08-2.5mm²

Series :

X-COM®

Housing Color :

Gray

Operating Temperature :

-

Height (Max) :

1.122 (28.50mm)

Depth :

28.5

Number of Positions :

2

HTS :

8536.90.40.00

Number of Circuits :

1

PPAP :

No

Product Status :

Active

Inflammability class of insulation material according to with UL94 :

V0

Length :

101

Terminal - Width :

5.0mm

Connectable conductor cross section solid-core :

0.08 - 4

Width :

5

Automotive :

No

Material Flammability Rating :

UL94 V-0

Voltage - IEC :

250 V

Color :

Gray

Height :

101

Connectable conductor cross section fine-strand without cable end sleeve :

0.08 - 4

Stripping Length :

8mm ~ 9mm

Mounting Type :

DIN Rail

ECCN (US) :

EAR99

Manufacturer :

Wago

Features :

-

Approvals :

CSA, UR
