3-794637-8
Or copy the link below:
- Mfr.Part #
- 3-794637-8
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- CONN HEADER SMD 8POS 3MM
- Stock
- 10
- In Stock ：
- 10
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Male Pins
- UL Flammability Code :
- 94V-0
- Connector Type :
- Header
- Number of Positions Loaded :
- All
- Length :
- 16mm
- Plating Thickness :
- 2.54μm
- Max Voltage Rating (AC) :
- 250V
- Number of Rows :
- 2
- Fastening Type :
- Locking Ramp
- Number of Conductors :
- ONE
- Contact Plating :
- Tin, Gold
- DIN Conformance :
- No
- VDE Tested :
- yes
- Current Rating :
- 5A
- Shrouding :
- Shrouded - 4 Wall
- Current Rating (Amps) :
- Varies by WireGAuge
- Body Depth :
- 0.364 inch
- Contact Finish Thickness - Mating :
- 15.0μin 0.38μm
- IEC Conformance :
- No
- Insulation Color :
- Black
- Additional Feature :
- ROHS AND ELV COMPLIANT
- Filter Feature :
- No
- Contact Finish - Post :
- Tin
- Published :
- 2008
- Contact Type :
- Male Pin
- Contact Material :
- Brass
- Contact Shape :
- Square
- Number of Ports :
- 1
- Factory Lead Time :
- 19 Weeks
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Mounting Type :
- Surface Mount
- PCB Thickness :
- 1.57mm
- Reliability :
- COMMERCIAL
- Contact Gender :
- Male
- Empty Shell :
- No
- Contact Retention :
- Without
- Sealable :
- No
- Mixed Contacts :
- No
- Polarization Key :
- POLARIZED HOUSING
- Durability :
- 75 Cycles
- Contact Finish - Mating :
- Gold
- Operating Temperature :
- -40°C~105°C
- Insulation Height :
- 0.364 9.25mm
- Pitch - Mating :
- 0.118 3.00mm
- Row Spacing - Mating :
- 0.118 (3.00mm)
- Lifecycle Status :
- ACTIVE (Last Updated: 5 days ago)
- Housing Material :
- Nylon
- Number Of PCB Rows :
- 2
- Flammability Rating :
- UL94 V-0
- Contact Current Rating :
- 5A
- Operating Supply Voltage :
- 250V
- Orientation :
- Vertical
- Approval Agency :
- CSA
- Termination :
- Solder
- Feature :
- Solder Retention
- Insulation Material :
- Polyamide (PA), Nylon
- Style :
- Board to Cable/Wire
- Packaging :
- Tape and Reel (TR)
- PCB Contact Pattern :
- RECTANGULAR
- Applications :
- GENERAL PURPOSE
- Series :
- Micro MATE-N-LOK
- Total Number of Contacts :
- 8
- Contact Finish Thickness - Post :
- 100.0μin 2.54μm
- Mount :
- Surface Mount
- Circuit Application :
- Power
- RoHS Status :
- RoHS Compliant
- Number of Terminations :
- 8
- Pbfree Code :
- yes
- Material Flammability Rating :
- UL94 V-0
- MIL Conformance :
- No
- Datasheets
- 3-794637-8
Micro MATE-N-LOK Series 2-Row Header Solder Brass Tape & Reel (TR) Surface Mount Gold Polyamide (PA), Nylon Board to Cable/Wire 0.364 9.25mm Height
3-794637-8 Overview
Packaging is in the form of Header.This device has a Surface Mount mounting type.An orange Tape & Reel (TR) case is used to package the product.Specifically, it is one of the products in the Micro MATE-N-LOK Series.Other features include ROHS AND ELV COMPLIANT, to name just a few.A variety of tasks can be performed using its 1 ports.There are a variety of possible applications for this device, including General Purpose.Several benefits come from the Solder Retention feature.There is a mounting hole at Surface Mount.A chip with 8 terminations can be found.It runs on 250V voltage.Devices operate at -40°C~105°C operating temperatures.
