292172-3
Or copy the link below:
- Mfr.Part #
- 292172-3
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- CONN HEADER SMD 3POS 2MM
- Stock
- 60
- In Stock ：
- 60
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Male Pins
- DIN Conformance :
- No
- Orientation :
- Vertical
- UL Flammability Code :
- 94V-0
- Sealable :
- No
- Housing Material :
- Nylon
- Mating Post Length :
- 4.4958mm
- Contact Length - Mating :
- 0.177 4.50mm
- Depth :
- 7.8mm
- Contact Shape :
- Circular
- Pitch - Mating :
- 0.079 2.00mm
- Contact Resistance :
- 20mOhm
- Shape :
- RECTANGULAR
- Applications :
- GENERAL PURPOSE
- Polarization Key :
- POLARIZED HOUSING
- Mounting Type :
- Surface Mount
- Contact Current Rating :
- 4A
- PCB Mount Retention :
- Without
- Termination :
- Solder
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Number of Conductors :
- ONE
- Min Operating Temperature :
- -40°C
- Height :
- 7.8mm
- PCB Thickness :
- 800μm
- Published :
- 2009
- Current Rating :
- 4A
- Insulator Color :
- Natural
- Operating Supply Voltage :
- 125V
- Wire/Cable Type :
- Discrete
- Voltage - Rated :
- 125VAC
- Plating Thickness :
- 2μm
- RoHS Status :
- RoHS Compliant
- Mount :
- Surface Mount
- Terminal Pitch :
- 2mm
- IEC Conformance :
- No
- Contact Type :
- Male Pin
- Contact Material :
- Brass
- Mixed Contacts :
- No
- Max Operating Temperature :
- 105°C
- Max Voltage Rating (DC) :
- 125.125kV
- Lifecycle Status :
- ACTIVE (Last Updated: 3 days ago)
- Approval Agency :
- UL
- Factory Lead Time :
- 21 Weeks
- Number of Positions Loaded :
- All
- Max Voltage Rating (AC) :
- 125V
- Mating Contact Pitch :
- 0.079 inch
- Housing Color :
- Black
- Total Number of Contacts :
- 3
- Filter Feature :
- No
- PCB Contact Pattern :
- STAGGERED
- Packaging :
- Tube
- Contact Finish - Mating :
- Tin
- Connector Type :
- Header
- Insulation Height :
- 0.307 7.80mm
- Lead Free :
- Lead Free
- Material Flammability Rating :
- UL94 V-0
- Width :
- 3.9878mm
- Insulation Material :
- Polyamide (PA6T), Nylon 6T, Glass Filled
- Contact Gender :
- Male
- Series :
- CT
- Current Rating (Amps) :
- Varies by WireGAuge
- Shrouding :
- Shrouded - 3 Wall
- Number of Positions :
- 3
- Style :
- Board to Cable/Wire
- Number Of PCB Rows :
- 2
- Number of Rows :
- 1
- Length :
- 8mm
- Flammability Rating :
- UL94 V-0
- ELV :
- Compliant
- Reliability :
- COMMERCIAL
- MIL Conformance :
- No
- Wire/Cable Gauge :
- 22 AWG
- Fastening Type :
- Detent Lock
- Pbfree Code :
- yes
- Datasheets
- 292172-3
CT Series 1-Row Header Solder Brass Tube Surface Mount Tin Polyamide (PA6T), Nylon 6T, Glass Filled 3-Position Board to Cable/Wire 0.307 7.80mm Height
292172-3 Overview
It comes in Header packaging.The device's mounting type is Surface Mount.In order to package the product, a Tube case is used.It belongs to the CT Series of products.It's best to use it when the temperature is below 105°C.This device must operate at a minimum temperature of -40°C.General Purpose is a possible application for the device.The part is mounted by Surface Mount.This memory's operating supply voltage is 125V.
