281696-4
Or copy the link below:
- Mfr.Part #
- 281696-4
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- CONN HEADER VERT 4POS 2.54MM
- Stock
- 576
- In Stock ：
- 576
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Male Pins
- Lead Free :
- Lead Free
- ELV :
- Compliant
- Contact Shape :
- Square
- Operating Temperature :
- -40°C~100°C
- Contact Finish Thickness - Mating :
- 16.0μin 0.41μm
- Lead Length :
- 2.9mm
- Contact Length - Mating :
- 0.276 7.00mm
- Shrouded End Dimension :
- 1.27 mm
- MIL Conformance :
- No
- Contact Current Rating :
- 3A
- Length :
- 10.16mm
- Contact Finish - Mating :
- Gold
- Contact Length - Post :
- 0.114 2.90mm
- Style :
- Board to Cable/Wire
- Lifecycle Status :
- ACTIVE (Last Updated: 1 week ago)
- Number of Positions :
- 4
- JESD-609 Code :
- e4
- IEC Conformance :
- No
- Contact Material :
- Phosphor Bronze
- Depth :
- 5.08mm
- Approval Agency :
- CSA
- Fastening Type :
- Friction Lock
- Contact Finish Thickness - Post :
- 98.4μin 2.50μm
- Additional Feature :
- AMPMODU
- Series :
- HE13/HE14
- Insulation Material :
- Thermoplastic
- Flammability Rating :
- UL94 V-0
- Mounting Type :
- Through Hole
- Mixed Contacts :
- No
- Filter Feature :
- No
- Material Flammability Rating :
- UL94 V-0
- Keyed :
- No
- Factory Lead Time :
- 15 Weeks
- Row Spacing :
- 2.54 mm
- Orientation :
- Vertical
- Current Rating :
- 3A
- Mount :
- Through Hole
- Connector Type :
- Header
- RoHS Status :
- RoHS Compliant
- Number of Positions Loaded :
- All
- Published :
- 2007
- Mating Post Length :
- 6.75mm
- Packaging :
- Bulk
- Pitch - Mating :
- 0.100 2.54mm
- Overall Contact Length :
- 0.492 12.50mm
- Insulation Resistance :
- 5GOhm
- Contact Type :
- Male Pin
- Pbfree Code :
- yes
- DIN Conformance :
- No
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Housing Color :
- Blue
- Termination :
- Solder
- Shrouding :
- Shrouded - 2 Wall
- Insulation Height :
- 0.449 11.40mm
- Contact Gender :
- Male
- Applications :
- GENERAL PURPOSE
- Number of Rows :
- 1
- Contact Finish - Post :
- Tin
- Datasheets
- 281696-4
HE13/HE14 Series 1-Row Header Solder Phosphor Bronze Bulk Through Hole Gold Thermoplastic 4-Position Board to Cable/Wire 0.449 11.40mm Height
281696-4 Overview
Packaging is in the form of Header.This device has a Through Hole mounting type.An orange Bulk case is used to package the product.Specifically, it is one of the products in the HE13/HE14 Series.Other features include AMPMODU, to name just a few.There are a variety of possible applications for this device, including General Purpose.There is a mounting hole at Through Hole.Devices operate at -40°C~100°C operating temperatures.
281696-4 Features
HE13/HE14 series
281696-4 Applications
There are a lot of TE Connectivity AMP Connectors
281696-4 Rectangular Connectors applications.
- Embedded systems
- Datacom
- Communication
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
