2814744
Or copy the link below:
- Mfr.Part #
- 2814744
- Manufacturer
- Phoenix Contact
- Package / Case
- Module
- Datasheet
- Download
- Description
- SENSOR CURRENT HALL 55A AC/DC
- Stock
- 7
- In Stock ：
- 7
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Phoenix Contact
- Product Category :
- Current Sensors
- Sensor Type :
- Hall Effect, Open Loop
- Voltage - Supply :
- 20V~30V
- Connector Type :
- Screw
- Package / Case :
- Module
- Voltage - Rated :
- 30V
- For Measuring :
- AC/DC
- Current Rating :
- 55A
- Weight :
- 135.679996g
- Number of Channels :
- 1
- Polarization :
- Bidirectional
- Polarity :
- Bidirectional, Unidirectional
- Lead Free :
- Lead Free
- Wire Gauge (Max) :
- 12 AWG
- Length :
- 99mm
- Mounting Type :
- DIN Rail
- Max Supply Current :
- 50mA
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Published :
- 2003
- Response Time :
- 330ms (AC), 40ms (DC)
- Factory Lead Time :
- 7 Weeks
- Width :
- 22.5mm
- Height :
- 114.5mm
- Color :
- Green
- Approval Agency :
- CE, UL
- Wire Gauge (Min) :
- 24 AWG
- Output :
- Ratiometric, Voltage and Current
- Max Input Current :
- 55A
- Max Output Voltage :
- 10V
- Accuracy :
- ±0.5%
- Operating Temperature :
- -20°C~60°C
- Mount :
- DIN Rail, Screw
- Min Output Voltage :
- -10V
- Operating Supply Voltage :
- 30V
- Packaging :
- Bulk
- RoHS Status :
- RoHS Compliant
- Housing Material :
- Polyamide
- Frequency :
- 15Hz~400Hz
- Sensing Method :
- Hall Effect
- Datasheets
- 2814744
2814744 Documents
Hall Effect, Open Loop Sensor 1-Channel Bidirectional -20°C~60°C 20V~30V 15Hz~400Hz Accuracy-±0.5%
2814744 Overview
To ensure safety, current sensors are encapsulated in Module packages. A protective Bulk is placed over these current sensors in order to prevent damage to the devices. It is recommended that current sensors do not supply a current greater than 50mA. For the current sensors, the current is 55A. When they operate, current sensors can supply 30V voltage.
2814744 Features
Moisture Sensitivity Level: 1 (Unlimited)
Operating Temperature: -20°C~60°C
1 Channels
Mounting Type: DIN Rail
Sensor Type: Hall Effect, Open Loop
Supply Voltage: 20V~30V
Frequency: 15Hz~400Hz
Module Package
2814744 Applications
There are a lot of Phoenix Contact
2814744 Current Sensors applications.
- DC and AC power monitoring
- Closed-L oop DC- and AC-Current Sensor Modules
- Leakage Current Sensors
- Industrial Monitoring and Control Systems
- Overcurrent Detection
- Frequency, Voltage, and Solar Inverters
- Electrical drives
- General purpose inverters
- AC variable speed drives
- Static converters for DC motor drives
