254589

Manufacturer :

TE Connectivity

Product Category :

Headers, Male Pins

Contact Finish Thickness - Mating :

-

Shrouding :

Shrouded - 4 Wall

Applications :

-

Operating Temperature :

-55°C ~ 125°C

Material Flammability Rating :

UL94 V-0

Contact Finish Thickness - Post :

157.5µin (4.00µm)

Voltage Rating :

-

Ingress Protection :

-

Product Status :

Active

Connector Type :

Header

Mounting Type :

Surface Mount

Termination :

Solder

Contact Length - Post :

-

Mated Stacking Heights :

-

Current Rating (Amps) :

1.7A per Contact

Contact Length - Mating :

0.157 (4.00mm)

Fastening Type :

Latch Holder

Contact Finish - Post :

Tin

Row Spacing - Mating :

0.050 (1.27mm)

Series :

SMC

Overall Contact Length :

-

Number of Positions Loaded :

All

Style :

Board to Cable/Wire

Contact Material :

COPPER ALLOY

Base Product Number :

-

Insulation Height :

0.266 (6.75mm)

Number of Positions :

32

Contact Shape :

Square

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

Contact Type :

Male Pin

Insulation Color :

Black

Contact Finish - Mating :

Gold

Insulation Material :

Liquid Crystal Polymer (LCP)

Pitch - Mating :

0.050 (1.27mm)

Features :

Board Guide, Pick and Place, Solder Retention

Number of Rows :

2
