2129260-2

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Centronics Connectors

Total Number of Contacts :

40

Lead Length :

1.524mm

Plating Thickness :

380 nm

Contact Pattern :

STAGGERED

Empty Shell :

yes

RoHS Status :

RoHS Compliant

Plating :

Nickel

Shell Material :

Stainless Steel

Factory Lead Time :

14 Weeks

Pitch :

609.6μm

Packaging :

Cut Tape (CT)

Reference Standard :

UL

Number of Positions :

40

Gender :

FEMALE

Mount :

Through Hole

Mixed Contacts :

No

Additional Feature :

LOW PROFILE, SHIELDED

Polarization Key :

POLARIZED HOUSING

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

IEC Conformance :

No

Feature :

Board Guide

Housing Material :

Thermoplastic

Operating Temperature (Max) :

85°C

Termination :

Solder

Contact Finish Thickness :

15.0μin 0.38μm

PCB Contact Pattern :

STAGGERED

DIN Conformance :

No

MIL Conformance :

No

Option :

GENERAL PURPOSE

Lifecycle Status :

ACTIVE (Last Updated: 5 months ago)

Orientation :

RIGHT ANGLE

Number of Rows :

2

Published :

2005

Material :

Brass

Reliability :

COMMERCIAL

Series :

CHAMP .024

Contact Finish :

Gold

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Sealable :

No

PCB Mounting Orientation :

RIGHT ANGLE

Filter Feature :

No

Number of Power Positions :

0

Connector Style :

Center Strip Contacts

Connector Type :

Receptacle

Number of Ports :

1

PCB Mount Retention :

With

Flammability Rating :

UL94 V-0

Current Rating :

500mA

Number Of PCB Rows :

2

Mounting Type :

Through Hole, Right Angle

Color :

Black

ECCN Code :

EAR99

Number of Conductors :

ONE
