206802-1
Or copy the link below:
- Mfr.Part #
- 206802-1
- Manufacturer
- TE Connectivity Aerospace Defense and Marine
- Package / Case
- Datasheet
- Download
- Description
- CONN D-SUB PLUG 37POS
- Stock
- 2
- In Stock ：
- 2
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Aerospace Defense and Marine
- Product Category :
- D-Sub Connector Assemblies
- Filter Feature :
- No
- Empty Shell :
- No
- Dielectric Material :
- Polyester, Glass Filled
- Housing Material :
- Polyester
- ELV :
- Compliant
- Option :
- GENERAL PURPOSE
- Connector Type :
- Plug for Male Contacts
- Lifecycle Status :
- ACTIVE (Last Updated: 2 days ago)
- Shell Size, Connector Layout :
- 4 DC C
- Reliability :
- COMMERCIAL
- Published :
- 2009
- Contact Design :
- PREASSEM CONN
- Gender :
- Male
- Mounting Type :
- Free Hanging (In-Line)
- Connector Style :
- D-Sub
- Orientation :
- Straight
- Contact Material :
- Copper
- Shell Material :
- Brass
- Hole Diameter :
- 3.9116 mm
- Sealable :
- No
- Total Number of Contacts :
- 37
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Packaging :
- Bulk
- Number of Rows :
- 2
- Contact Plating :
- Gold
- UL Flammability Code :
- 94V-0
- DIN Conformance :
- No
- Note :
- Contacts Not Included
- MIL Conformance :
- No
- IEC Conformance :
- No
- Shell Material, Finish :
- Brass, Gold Plated
- Flange Feature :
- Housing/Shell (Unthreaded)
- Mount :
- Free Hanging, Panel
- Series :
- AMPLIMITE 109
- HTS Code :
- 8536.69.40.30
- ECCN Code :
- EAR99
- Contact Type :
- Signal
- Body Depth :
- 0.414 inch
- Current Rating :
- 7.5A
- Factory Lead Time :
- 8 Weeks
- Reference Standard :
- UL, CSA
- RoHS Status :
- RoHS Compliant
- Contact Style :
- Crimp
- Color :
- Blue
- Mating Information :
- MULTIPLE MATING PARTS AVAILABLE
- Length :
- 69.31mm
- Mixed Contacts :
- No
- Body Breadth :
- 0.494 inch
- Number of Positions :
- 37
- Datasheets
- 206802-1
206802-1 datasheet pdf and D-Sub, D-Shaped Connectors - Housings product details from TE Connectivity Aerospace, Defense and Marine stock available at Xinshop
