2-794621-4
Or copy the link below:
- Mfr.Part #
- 2-794621-4
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- CONN HEADER SMD R/A 24POS 3MM
- Stock
- 22,037
- In Stock ：
- 22,037
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Male Pins
- Current Rating :
- 5A
- Filter Feature :
- No
- Durability :
- 30 Cycles
- Radiation Hardening :
- No
- Flammability Rating :
- UL94 V-0
- Contact Finish Thickness - Post :
- 100.0μin 2.54μm
- Number of Positions :
- 24
- ECCN Code :
- EAR99
- Connector Type :
- Header
- Additional Feature :
- POLARIZED
- ELV :
- Non-Compliant
- JESD-609 Code :
- e0
- IEC Conformance :
- No
- Termination :
- Solder
- Pbfree Code :
- No
- HTS Code :
- 8536.69.40.40
- Insulation Material :
- Polyamide (PA), Nylon
- Number of Conductors :
- ONE
- Voltage - Rated :
- 250V
- Contact Finish Thickness - Mating :
- 100.0μin 2.54μm
- Body Breadth :
- 0.341 inch
- Orientation :
- RIGHT ANGLE
- DIN Conformance :
- No
- Contact Shape :
- Square
- Body Length or Diameter :
- 1.575 inch
- Mating Contact Pitch :
- 0.118 inch
- Row Spacing - Mating :
- 0.118 (3.00mm)
- Published :
- 2005
- UL Flammability Code :
- 94V-0
- Insulation Height :
- 0.290 7.37mm
- Number of Rows :
- 2
- Number of Positions Loaded :
- All
- PCB Contact Pattern :
- RECTANGULAR
- Insulation Color :
- Black
- Reference Standard :
- UL, CSA
- Reliability :
- COMMERCIAL
- Contact Plating :
- Lead, Tin
- Mount :
- Surface Mount
- Polarization Key :
- POLARIZED HOUSING
- Series :
- Micro MATE-N-LOK
- Packaging :
- Tape and Reel (TR)
- Style :
- Board to Cable/Wire
- Total Number of Contacts :
- 24
- Applications :
- GENERAL PURPOSE
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Number Of PCB Rows :
- 2
- Factory Lead Time :
- 13 Weeks
- Housing Material :
- Nylon
- Body Depth :
- 0.615 inch
- Operating Temperature :
- -40°C~105°C
- Lead Free :
- Contains Lead
- Material Flammability Rating :
- UL94 V-0
- Fastening Type :
- Locking Ramp
- Contact Type :
- Male Pin
- Plating Thickness :
- 100μin
- Feature :
- Board Lock
- RoHS Status :
- Non-RoHS Compliant
- Insulation Resistance :
- 100000000Ohm
- Current Rating (Amps) :
- Varies by WireGAuge
- Pitch - Mating :
- 0.118 3.00mm
- Contact Finish - Mating :
- Tin-Lead
- Mounting Type :
- Surface Mount, Right Angle
- Shrouding :
- Shrouded - 4 Wall
- Terminal Pitch :
- 3mm
- MIL Conformance :
- No
- Dielectric Withstanding Voltage :
- 1500VAC V
- Mixed Contacts :
- No
- Contact Material :
- Brass
- Datasheets
- 2-794621-4
2-794621-4 Documents
Micro MATE-N-LOK Series 2-Row Header Solder Brass Tape & Reel (TR) Surface Mount, Right Angle Tin-Lead Polyamide (PA), Nylon 24-Position Board to Cable/Wire 0.290 7.37mm Height
2-794621-4 Overview
This product is packaged in a Header box.Surface Mount, Right Angle indicates that the device is mounted.An Tape & Reel (TR) case is utilized for packaging the product.The product is a part of the Micro MATE-N-LOK Series.Furthermore, there are other features such as POLARIZED, to name a few.There is the possibility of using the device for General Purpose.In many ways, Board Lock makes it more powerful.By Surface Mount, the part is mounted.Operating temperature is set to -40°C~105°C.
