09120063141
Or copy the link below:
- Mfr.Part #
- 09120063141
- Manufacturer
- HARTING
- Package / Case
- Datasheet
- Download
- Description
- INSERT FEMALE 4+2POS+1GND CRIMP
- Stock
- 10
- In Stock ：
- 10
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- HARTING
- Product Category :
- Heavy Duty Connector Inserts, Modules
- DIN Conformance :
- No
- Depth :
- 40mm
- Pbfree Code :
- yes
- Max Current Rating :
- 40A
- Voltage - Rated :
- 690V
- Option :
- GENERAL PURPOSE
- Orientation :
- Straight
- Housing Material :
- Polycarbonate (PC)
- Termination Style :
- Crimp
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Factory Lead Time :
- 5 Weeks
- MIL Conformance :
- No
- Number of Contacts :
- 7
- Contact Type :
- Han® C, Han® D
- Gender :
- FEMALE
- Contact Material :
- NOT SPECIFIED
- RoHS Status :
- ROHS3 Compliant
- Operating Temperature :
- -40°C~125°C
- Current Rating :
- 40A
- REACH SVHC :
- No SVHC
- Connector Type :
- Insert without Contacts
- Series :
- Han® Q
- Test Current :
- 40A
- Contact Finish - Mating :
- NOT SPECIFIED
- Packaging :
- Bulk
- Voltage - Rated DC :
- 690V
- Number of Positions :
- 4+2+Ground
- Length :
- 41.6mm
- Color :
- Gray
- IEC Conformance :
- No
- Wire Gauge (Max) :
- 26 AWG
- Flammability Rating :
- UL94 V-0
- Number of Rows :
- 3
- Wire Gauge (Min) :
- 10 AWG
- Material Flammability Rating :
- UL94 V-0
- Datasheets
- 09120063141
