ZUS152412

Manufacturer :

Cosel

Product Category :

Package / Case :

6-DIP Module

Moisture Sensitivity Level (MSL) :

Not Applicable

Length :

50mm

Efficiency :

83%

Output Current :

1.3A

Operating Temperature :

-20°C~71°C With Derating

Voltage - Input (Max) :

36V

Current - Output 1 :

1.3A

Number of Terminations :

6

Height :

8.382mm

Terminal Position :

Dual

Voltage - Input (Min) :

18V

Voltage - Isolation :

500V

RoHS Status :

RoHS Compliant

Width :

45mm

Approval Agency :

CE, TUV, cULus

Size / Dimension :

1.97Lx1.77W x 0.33 H 50.0mmx45.0mmx8.5mm

Number of Outputs :

1

Mount :

PCB, Through Hole

Trim/Adjustable Output :

yes

Series :

ZUS (15W)

Pbfree Code :

yes

Depth :

8.5mm

Output Voltage :

12V

Weight :

56.699046g

Terminal Form :

PIN/PEG

JESD-30 Code :

R-XDMA-P6

Mounting Type :

Through Hole

Applications :

ITE (Commercial)

Input Voltage-Nom :

24V

Reach Compliance Code :

Unknown

Lead Free :

Lead Free

Pin Count :

6

Nominal Input Voltage :

24V

Input Current :

780mA

Number of Functions :

1

Feature :

Remote On/Off, OCP, OVP

ECCN Code :

EAR99

Type :

Isolated Module

Output Power :

15W

Published :

2005
