W1911

Manufacturer :

Pulse Electronics

Product Category :

RF Antennas

RoHS :

Details

Package :

Bulk

Length :

49 mm

Ingress Protection :

-

Maximum Operating Temperature :

+ 85 C

Transmission Power-Max :

5 W

Frequency (Min) :

824/1710/1920(MHz)

Characteristic Impedance :

50 Ω

Operating Frequency-Max :

2170 MHz

Applications :

GSM, WCDMA

Technology :

Penta Band Stubby

Gain :

1dBi, 2dBi, 2.5dBi

Antenna Gain :

2.5DBI(MAX)

Center Frequency :

850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz

Cable Type :

-

Series :

-

Product :

Indoor Antennas

Termination :

Connector, RP-SMA Male

Application :

M2M

Impedance :

50 OHM

Omnidirectional :

yes

Diameter :

10.4 mm

Features :

-

Number of Bands :

5

Mounting Type :

Connector Mount

Min Operating Temperature :

-40 °C

Frequency :

960/1990/2170(MHz)

Category :

RF/IF and RFID

Power Rating :

5 W

Packaging :

Bulk

Height :

48.9966 mm

Frequency (Center/Band) :

850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz

Antenna Connector Type :

RP-SMA Male

Additional Feature :

RP-SMA-M

Reach Compliance Code :

Compliant

Construction :

Coaxial

Operating Frequency-Min :

824 MHz

Factory Lead Time :

8 Weeks

Brand :

Pulse Electronics

VSWR :

-

Product Category :

Antennas

Return Loss :

-4dB, -6dB

RF Family/Standard :

Cellular

Radiation Hardening :

No

Style :

Stubby

Mounting Style :

Panel Mount

Antenna Type :

Whip, Straight

Rad Hardened :

No

Frequency Range :

824MHz ~ 960MHz, 1.71GHz ~ 2.17GHz

Schedule B :

8529109000/8529109000/8529109000/8529109000/8529109000

Type :

Stubby

RF/Microwave Device Type :

MOBILE STATION ANTENNA

Operating Temperature (Max) :

85C

Termination Style :

Connector

Product Status :

Active

Minimum Operating Temperature :

- 40 C

Operating Temperature (Min) :

-40C

Family :

RF Antennas

Max Operating Temperature :

85 °C

Height (Max) :

1.929" (49.00mm)

Frequency Group :

Wide Band

Product Type :

Cellular Antennas - GSM, LTE, 2G/3G/4G/5G

Subcategory :

Antennas

Polarization :

Linear

REACH SVHC :

No SVHC

For Use With :

Penta band EU, US GSM, WCDMA

Connector Type :

SMA

Operating Temperature Classification :

INDUSTRIALC
