UPD5716GR-E1-A
- Mfr.Part #
- UPD5716GR-E1-A
- Manufacturer
- CEL (California Eastern Laboratories)
- Package / Case
- 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
- Datasheet
- Download
- Description
- IC RF SWITCH 2.15GHZ 16HTSSOP
- Stock
- 6,000
- In Stock :
- 6,000
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- CEL (California Eastern Laboratories)
- Product Category :
- RF Switches
- Minimum Isolation Voltage :
- 25 dB
- Operating Frequency-Max :
- 2150 MHz
- Package / Case :
- 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
- Operating Supply Voltage :
- 5 V
- Frequency Range :
- 250MHz ~ 2.15GHz
- Number of Switches :
- 4
- Product Status :
- Obsolete
- Series :
- -
- Operating Frequency-Min :
- 250 MHz
- Isolation :
- 29dB
- Mounting :
- Surface Mount
- Reach Compliance Code :
- Compliant
- Operating Temperature :
- -40 to 85 °C
- Input Power-Max (CW) :
- 15.05 dBm
- Test Frequency :
- 2.15GHz
- Circuit :
- -
- Technology :
- CMOS
- Characteristic Impedance :
- 50 Ω
- Package :
- Bulk
- Voltage - Supply :
- 4V ~ 5.5V
- Pbfree Code :
- yes
- IIP3 :
- -
- JESD-609 Code :
- e6
- Switch Configuration :
- 4 DPDT
- Features :
- -
- Topology :
- Absorptive
- Insertion Loss :
- 6.7dB
- RF/Microwave Device Type :
- SPDT
- High Control Voltage :
- 4, 5.5 V
- Supplier Package :
- HTSSOP
- P1dB :
- -
- Terminal Finish :
- Tin/Bismuth (Sn/Bi)
- Supplier Device Package :
- 16-HTSSOP
- Pin Count :
- 16
- RF Type :
- GENERAL PURPOSE
- Impedance :
- 50Ohm
- Construction :
- COMPONENT
- Datasheets
- UPD5716GR-E1-A
