TUA 6041-2

Manufacturer :

Infineon Technologies

Product Category :

Video Processing

Input Frequency-Min (RF) :

48.25MHz

Base Part Number :

TUA6041

Terminal Position :

QUAD

Temperature Grade :

Other

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Number of Bands :

3

Published :

2006

Length :

7mm

Type :

Tuner

Qualification Status :

Not Qualified

JESD-30 Code :

S-XQCC-N48

Width :

7mm

Supply Voltage-Min (Vsup) :

3V

Operating Temperature (Min) :

-20°C

Operating Temperature (Max) :

85°C

ECCN Code :

EAR99

Surface Mount :

yes

Reach Compliance Code :

Unknown

Packaging :

Tape and Reel (TR)

Package / Case :

48-VFQFN Exposed Pad

Number of Terminations :

48

RoHS Status :

RoHS Compliant

HTS Code :

8542.39.00.01

Built-in IF Amplifier :

yes

Number of Functions :

1

Applications :

NTSC, PAL

Mounting Type :

Surface Mount

Input Frequency-Max (RF) :

863.25MHz

Noise Figure :

8 dB

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Power Supplies :

3.3V

Supply Voltage-Max (Vsup) :

5.5V

Terminal Pitch :

0.5mm

Terminal Form :

NO LEAD

Height Seated (Max) :

0.9mm

Pin Count :

48
