STR-A6051M

Manufacturer :

Sanken Electric Co., Ltd.

Product Category :

AC DC Converters, Offline Switches

Base Product Number :

STR-A6051

Surface Mount :

No

Length :

9.4mm

Package :

Tube

Terminal Position :

Dual

Mounting Type :

Through Hole

Terminal Pitch :

2.54mm

Control Features :

-

HTS Code :

8542.39.00.01

Published :

2011

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Power (Watts) :

31W

Input Voltage-Nom :

18V

Pbfree Code :

yes

Frequency - Switching :

67kHz

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Output Isolation :

Isolated

Topology :

Flyback

Operating Temperature :

-20°C~125°C TA

Control Mode :

CURRENT-MODE

Supplier Device Package :

8-DIP

Analog IC - Other Type :

SWITCHING CONTROLLER

Duty Cycle :

83%

Product Status :

Not For New Designs

Number of Functions :

1

JESD-30 Code :

R-PDIP-T7

Max Power Dissipation :

16W

RoHS Status :

RoHS Compliant

ECCN Code :

EAR99

Package / Case :

8-DIP (0.300, 7.62mm), 7 Leads

Height Seated (Max) :

4.5mm

Voltage - Supply (Vcc/Vdd) :

8.1V~32V

Voltage - Breakdown :

650V

Fault Protection :

Current Limiting, Over Load, Over Temperature, Over Voltage

Factory Lead Time :

12 Weeks

Series :

STR-A6000

Internal Switch(s) :

yes

Packaging :

Tube

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Control Technique :

PULSE WIDTH MODULATION

Width :

7.62mm

Number of Terminations :

7

Voltage - Start Up :

15.3V
