SN74LVTH125DBR

Manufacturer :

Texas Instruments

Product Category :

Buffers, Drivers, Receivers, Transceivers

Pbfree Code :

yes

Logic Function :

Buffer, Inverting

Radiation Hardening :

No

REACH SVHC :

No SVHC

Supply Voltage :

3.3V

Output Type :

3-STATE

Load Capacitance :

50pF

Logic Type :

Buffer, Non-Inverting

Width :

5.3mm

Mount :

Surface Mount

Series :

74LVTH

Terminal Form :

Gull wing

Terminal Position :

Dual

Number of Channels :

4

ECCN Code :

EAR99

Pin Count :

14

Number of Functions :

4

Voltage - Supply :

2.7V~3.6V

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Packing Method :

TR

Package / Case :

14-SSOP (0.209, 5.30mm Width)

Mounting Type :

Surface Mount

Lifecycle Status :

ACTIVE (Last Updated: 5 days ago)

JESD-609 Code :

e4

Factory Lead Time :

6 Weeks

Number of Bits per Element :

1

Base Part Number :

74LVTH125

Contact Plating :

Gold

RoHS Status :

ROHS3 Compliant

Propagation Delay :

2.1 ns

Height :

2mm

Packaging :

Tape and Reel (TR)

Count Direction :

Unidirectional

Number of Pins :

14

Polarity :

Non-Inverting

Operating Temperature :

-40°C~85°C TA

Number of Ports :

2

Terminal Pitch :

0.65mm

Family :

LVT

Control Type :

ENABLE LOW

Current - Output High, Low :

32mA 64mA

Operating Supply Voltage :

3.3V

Termination :

SMD/SMT

Peak Reflow Temperature (Cel) :

260

Number of Output Lines :

3

Quiescent Current :

7mA

Length :

6.2mm

Number of Terminations :

14

Lead Free :

Lead Free

Turn On Delay Time :

5.7 ns

Supply Voltage-Min (Vsup) :

2.7V

Thickness :

1.95mm
