SLD03210

Share

Or copy the link below:

Mfr.Part #
SLD03210
Manufacturer
Celduc
Package / Case
4-SIP
Datasheet
Download
Description
SSR 2,5A/60VDC/CTRL18-32VDC
Stock
43,513
In Stock :
43,513

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Celduc
Product Category :
Solid State Relays
Number of Poles :
1
Minimum Load Current (mA) :
1
Package / Case :
4-SIP
Product Status :
Active
Maximum Output Current (A) :
2.5
Maximum Operating Temperature :
+80°C
Operating Temperature Range :
-20 → +80°C
Mounting Type :
PCB Mount
Depth :
5mm
RoHS Status :
Supplier Unconfirmed
Mounting :
Through Hole
Output Type :
DC
Maximum Output Voltage (V) :
60
Series :
SP-ST-SL
Circuit :
SPST-NO (1 Form A)
Maximum Off-State Leakage Current (uA) :
1000
Supplier Device Package :
4-SIP
Input Type :
DC
ECCN (US) :
EAR99
Voltage - Load :
0 V ~ 60 V
Pin Count :
4
Maximum Operating Temperature (°C) :
80
Minimum Operating Temperature :
-20°C
Termination Style :
-
Package Width :
5
PCB changed :
4
I/O Isolation Voltage (V) :
2500(RMS)
Peak Non-Repetitive Surge Current (A) :
6
Terminal Type :
PCB Pin
Minimum Operating Temperature (°C) :
-20
Maximum Turn-Off Time (ms) :
0.6
Relay Type :
DC Interface Relay
Maximum Input Voltage (V) :
32
Length :
28mm
Range :
SP-ST-SL
Output Device :
MOSFET
Height :
15mm
Package :
Box
Standards Met :
CE, EAC, cURus
Maximum Turn-On Time (ms) :
0.05
Package Length :
28
Dimensions :
28 x 5 x 15mm
Voltage - Input :
24VDC
Load Current :
2.5 A
Maximum Input Current (mA) :
10.2
Package Height :
15
On-State Resistance (Max) :
200 mOhms
Introducing Solid State Relays Celduc SLD03210 from Chip IC,where excellence meets affordability. This product stands out with its Package / Case:4-SIP, Mounting Type:PCB Mount, Circuit:SPST-NO (1 Form A), SLD03210 pinout, SLD03210 datasheet PDF, SLD03210 amp .Beyond Solid State Relays Celduc SLD03210 ,we also offer AQY412SX, AQW214EH, AQY211G2SX, Our vast inventory has you covered. Contact us now for immediate solutions.

Celduc SLD03210


SLD03210 datasheet pdf and Solid State Relays product details from Celduc Relais stock available at
