SF11G

Manufacturer :

Taiwan Semiconductor

Product Category :

Diodes - Rectifiers - Single

Capacitance @ Vr, F :

20pF @ 4V 1MHz

Factory Lead Time :

10 Weeks

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Current - Reverse Leakage @ Vr :

5µA @ 50V

Current - Average Rectified (Io) :

1A

Operating Temperature - Junction :

-55°C~150°C

Output Current-Max :

1A

Package / Case :

DO-204AL, DO-41, Axial

JESD-30 Code :

O-PALF-W2

Operating Temperature (Max) :

150°C

Mounting Type :

Through Hole

Voltage - DC Reverse (Vr) (Max) :

50V

Terminal Form :

Wire

Diode Element Material :

SILICON

Number of Terminations :

2

RoHS Status :

ROHS3 Compliant

Packaging :

Tape and Reel (TR)

Voltage - Forward (Vf) (Max) @ If :

950mV @ 1A

Surface Mount :

No

Number of Elements :

1

Additional Feature :

HIGH RELIABILITY, LOW POWER LOSS

ECCN Code :

EAR99

Configuration :

Single

Diode Type :

Standard

Reverse Recovery Time :

35ns

Non-rep Pk Forward Current-Max :

30A

Case Connection :

Isolated

Rep Pk Reverse Voltage-Max :

50V
