PVT412APBF
- Mfr.Part #
- PVT412APBF
- Manufacturer
- Infineon Technologies
- Package / Case
- 6-DIP (0.300, 7.62mm)
- Datasheet
- Download
- Description
- SSR RELAY SPST-NO 240MA 0-400V
- Stock
- 4
- In Stock :
- 4
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Infineon Technologies
- Product Category :
- Solid State Relays
- Published :
- 2008
- Relay Type :
- Relay
- Packaging :
- Tube
- Operating Supply Voltage :
- 400V
- Overall Height :
- 3.4mm
- Number of Channels :
- 1
- Input Current :
- 25mA
- Current Rating :
- 360mA
- On-State Resistance (Max) :
- 6Ohm
- Radiation Hardening :
- No
- Rise Time :
- 3ms
- Isolation Voltage :
- 4kV
- Voltage - Input :
- 1.2VDC
- Termination :
- PC Pin
- Optoelectronic Device Type :
- TRANSISTOR OUTPUT SSR
- Voltage - Load :
- 0V~400V
- Package / Case :
- 6-DIP (0.300, 7.62mm)
- Fall Time (Typ) :
- 500 µs
- On-State Current-Max :
- 0.24A
- Factory Lead Time :
- 16 Weeks
- Circuit :
- SPST-NO (1 Form A)
- Number of Pins :
- 6
- Output Type :
- AC, DC
- Throw Configuration :
- SPST
- Input Type :
- AC/DC
- Control Current :
- 0.003A
- Max Input Current :
- 25mA
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Mount :
- PCB, Through Hole
- Resistance :
- 6Ohm
- Lead Free :
- Lead Free
- Capacitance :
- 40pF
- Max Operating Temperature :
- 85°C
- Max Output Voltage :
- 400V
- Termination Style :
- PC Pin
- Min Operating Temperature :
- -40°C
- RoHS Status :
- ROHS3 Compliant
- Mounting Type :
- Through Hole
- Number of Elements :
- 1
- Approval Agency :
- UL
- Forward Current :
- 25mA
- Series :
- PVT, HEXFET®
- Output Current :
- 240mA
- Datasheets
- PVT412APBF
