PT2L7LB2
Or copy the link below:
- Mfr.Part #
- PT2L7LB2
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Datasheet
- Download
- Description
- RELAY GEN PURPOSE DPDT 12A 12V
- Stock
- 3
- In Stock ：
- 3
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Power Relays, Over 2 Amps
- Power Consumption :
- 750 mW
- Series :
- PT, SCHRACK
- Mounting Style :
- Din-Rail
- Product Category :
- Industrial Relays
- Coil Insulation :
- -
- Package :
- Bulk
- Contact Form :
- DPDT (2 Form C)
- RoHS :
- Details
- Turn Off Voltage (Min) :
- 1.2 VDC
- Coil Suppression Diode :
- yes
- Product :
- Industrial Relays
- Coil Termination :
- Screw
- Dropout Volt :
- 1.2VDC
- Mounting Type :
- DIN Rail
- Must Release Voltage :
- 1.2 VDC
- Product Depth (mm) :
- 27.2(mm)
- Product Type :
- Industrial Relays
- Brand :
- TE Connectivity
- Manufacturer :
- TE Connectivity
- Coil Voltage :
- 12VDC
- Release Time :
- 18ms
- Termination Style :
- Screw Terminal
- Contact Arrangement :
- DPDT
- Length :
- 73.5 mm
- Packaging :
- Bulk
- Coil Voltage DC :
- 12
- Contact Rating (Current) :
- 12A
- Voltage Rating (VAC) :
- 400(V)
- Operating Temp Range :
- -40C to 70C
- Rad Hardened :
- No
- Coil Type :
- Non Latching
- Type :
- RELAY PACKAGE
- Relay Type :
- General Purpose with Socket
- Seal Rating :
- -
- Contact Current Rating :
- 12(A)
- Relay Construction :
- Non-Latching
- Operate Time :
- 15ms
- Features :
- Diode, LED Indicator, Mechanical Indicator, Test Button
- Maximum Power Rating :
- 3KVA
- Moisture Sensitivity Level (MSL) :
- --
- Product Length (mm) :
- 77(mm)
- Subcategory :
- Relays
- LED Indicator :
- yes
- Pick-up Voltage (Max) :
- 9VDC
- Switching Voltage :
- 400VAC - Max
- Coil Current :
- 62.5mA
- Operating Temperature :
- -40°C ~ 70°C
- Coil Power :
- 750 mW
- Product Height (mm) :
- 78.3(mm)
- IP Rating :
- -
- Seal :
- Unsealed
- Contact Termination :
- Screw
- Pin Count :
- 15
- Coil Resistance :
- 192 Ohms
- Height :
- 58 mm
- Width :
- 27 mm
- Contact Material :
- Silver Nickel (AgNi)
- Must Operate Voltage :
- 9 VDC
- Product Status :
- Active
- Base Product Number :
- PT2L7
- Turn On Voltage (Max) :
- 9 VDC
- Datasheets
- PT2L7LB2
