PE8271

Manufacturer :

Pasternack

Product Category :

Coaxial Connector (RF) Adapters

Application :

GENERAL PURPOSE

Mounting :

Surface Mount

ET Product-Min :

5 V-us

Physical Dimension :

L7.62XB7.62 (mm)

Width :

8.89 mm

Operating Temperature (Max) :

70°C

Type :

Electrostatically Shielded

Minimum Operating Temperature :

0 C

Weight :

-

Primary Inductance :

500 μH

Packaging :

Tube

Size / Dimension :

0.300 L x 0.300 W (7.62mm x 7.62mm)

Maximum Operating Temperature :

+ 70 C

Inductance :

500 μH

Mounting Feature :

Surface Mount

Length :

12.7 mm

Mounting Type :

Surface Mount

Height - Seated (Max) :

0.215 (5.46mm)

For Use With/Related Products :

-

Height :

6.35 mm

Transformer Type :

PULSE TRANSFORMER

Number of Functions :

1

Surface Mount :

yes

Lead Style :

Gull wing

Packing Method :

Tube

Product Depth (mm) :

10.54(mm)

Mounting Style :

Surface Mount

Isolation Voltage :

1500V

Pulse Rise Time-Max :

4.2ns

Series :

-

Operating Temperature :

0 to 70 °C

Reach Compliance Code :

Compliant

High Potential :

1500Vrms

Turns Ratio :

1:1

Product Length (mm) :

7.62(mm)

Turns Ratio (NpNs) :

1CT:1CT

ECCN Code :

EAR99

Operating Temp Range :

0C to 70C

Product Status :

Active

Package :

Tube

Pin Count :

6
