MOC3023X

Manufacturer :

Isocom Components

Product Category :

Optoisolators - Triac, SCR Output

Current - LED Trigger (Ift) (Max) :

5mA

Mount :

Through Hole

Packaging :

Tube

REACH SVHC :

No SVHC

Factory Lead Time :

2 Weeks

Max Input Current :

50mA

Package / Case :

6-DIP (0.300, 7.62mm)

Voltage - Isolation :

5300Vrms

Mounting Type :

Through Hole

Voltage - Off State :

400V

Current - Hold (Ih) :

100μA

Output Voltage :

400V

Static dV/dt (Min) :

10V/μs (Typ)

Operating Temperature :

-40°C~100°C

Number of Pins :

6

Zero Crossing Circuit :

No

Number of Channels :

1

RoHS Status :

ROHS3 Compliant

Current - DC Forward (If) (Max) :

50mA

Voltage - Forward (Vf) (Typ) :

1.2V

Output Type :

Triac

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Input Current :

10mA

Approval Agency :

UR, VDE
