ME00S6NCGD

Manufacturer :

C&K

Product Category :

Actuator Material :

Stainless Steel

Contact Style :

Non-Shorting

Depth :

13.34mm

Actuator Length :

13.59mm

Voltage - Rated DC :

28V

Max Voltage Rating (AC) :

125V

Panel Cutout Dimensions :

Circular - 6.60mm Dia

Electrical Life :

10000 Cycles

Depth Behind Panel :

11.44mm

Termination Style :

PC Pin

Orientation :

Straight

Factory Lead Time :

20 Weeks

Contact Material :

COPPER ALLOY

Current Rating (Amps) :

250mA AC/DC

Series :

M

Current Rating :

250mA

Max Current Rating :

250mA

Index Stops :

Continuous

Termination :

PC Pins

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Operating Force :

2.880 ~ 5.041gfm

Mounting Type :

Panel Mount, Through Hole

Contact Plating :

Gold, Silver

Max Voltage Rating (DC) :

28V

Min Operating Temperature :

-30°C

Max Operating Temperature :

85°C

Actuator Type :

Round (3.17mm Dia), Slotted

Housing Material :

Zinc

Number of Positions :

10

Length :

13.34mm

Contact Timing :

Non-Shorting (BBM)

Voltage - Rated AC :

125V

Index Angle :

36 °

RoHS Status :

ROHS3 Compliant

Mount :

Panel, Through Hole

Circuit per Deck :

SP10T

Number of Decks :

1

Contact Finish :

Gold
