LCB127

Manufacturer :

Littelfuse

Product Category :

Solid State Relays

Isolation Voltage-Max :

3750 V

Minimum Operating Temperature :

- 40 C

Series :

LCB, OptoMOS®

Max Output Voltage :

250V

Factory Lead Time :

6 Weeks

JESD-609 Code :

e3

Maximum Operating Temperature :

+ 85 C

HTS Code :

8541.40.95.00

Throw Configuration :

SPST

Voltage - Load :

0V~250V

Overall Height :

3 mm

Package Type :

PDIP

Output Voltage (Max) :

250(V)

Voltage - Input :

1.2VDC

Output Device :

MOSFET

Published :

2011

Control Current :

0.005 A

Operating Temp Range :

-40C to 85C

Number of Elements :

1

Output Voltage :

250V

Max Operating Temperature :

85°C

Manufacturer :

IXYS

Input Type :

DC

Product Type :

SSR - Solid State Relays

Product Category :

Solid State Relays - PCB Mount

Mounting :

Through Hole

Type :

Ground-Start

Forward Current-Max :

0.05 A

Min Operating Temperature :

-40°C

Input Voltage :

1.4(V)

Output Type :

AC, DC

Contact Form :

SPST (1 Form B)

Rad Hardened :

No

Pin Count :

6

Length :

8.38mm

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Tradename :

Clare

Termination :

PC Pin

Load Current :

200mA

Package :

Tube

Input Current :

50mA

Product :

Solid State Relays

Output Current :

200mA

RoHS :

Details

Max Output Current :

200mA

Terminal Finish :

Matte Tin (Sn)

Mount :

Through Hole

Packaging :

Tube

Brand :

IXYS Integrated Circuits

RoHS Status :

ROHS3 Compliant

Circuit Arrangement :

1 Form B

Additional Feature :

CMOS COMPATIBLE, HIGH RELIABILITY, UL RECOGNIZED

Product Status :

Active

Max Power Dissipation :

800mW

Termination Style :

PC Pin

Pbfree Code :

yes

Control Voltage :

0.9 V

Mounting Type :

Through Hole

Mounting Style :

PCB Mount

Overall Length :

9 mm

Output Circuit Type :

MOSFET

Optoelectronic Device Type :

TRANSISTOR OUTPUT SSR

On-State Resistance (Max) :

10Ohms

Radiation Hardening :

No

Subcategory :

Relays

Isolation Voltage :

3.75kV

Max Input Current :

50mA

Number of Pins :

6

Circuit :

SPST-NC (1 Form B)

Relay Type :

Relay

Operating Temperature Classification :

Industrial

Supplier Device Package :

6-DIP

Configuration :

Single

Height :

3.3mm

Width :

6.35mm

Resistance :

10Ohm

Reach Compliance Code :

Unknown

Lead Free :

Lead Free

Package / Case :

6-DIP (0.300, 7.62mm)
