GBS4B

Manufacturer :

Diotec Semiconductor

Product Category :

Diodes - Bridge Rectifiers

Peak Forward Voltage (V) :

1.05@2A

Subcategory :

Bridge Rectifier Diodes

Military :

No

JESD-30 Code :

R-PSIP-T4

Peak Reverse Current (uA) :

5

RoHS Status :

Yes with exemptions

Peak Average Forward Current (A) :

4@Ta=50C

Package Width :

3.5

Diode Element Material :

SILICON

Peak RMS Reverse Voltage (V) :

70

Package Shape :

RECTANGULAR

Diode Type :

BRIDGE RECTIFIER DIODE

Minimum Operating Temperature (°C) :

-50

ECCN (US) :

EAR99

Packaging :

Box

Rep Pk Reverse Voltage-Max :

100 V

Peak Reflow Temperature (Cel) :

260

Surface Mount :

No

Qualification Status :

Not Qualified

Package Height :

10

Terminal Form :

THROUGH-HOLE

Bridge Type :

Single Phase

Mounting :

Through Hole

Package Length :

19

Non-rep Pk Forward Current-Max :

90 A

Number of Terminals :

4

Output Current-Max :

2.3 A

Manufacturer :

Diotec Semiconductor AG

Terminal Position :

Single

Pin Count :

4

Number of Phases :

1

Number of Elements :

4

ECCN Code :

EAR99

Peak Non-Repetitive Forward Surge Current (A) :

90

Peak Reverse Repetitive Voltage (V) :

100

Maximum Operating Temperature (°C) :

150

Configuration :

Single

Reach Compliance Code :

Compliant

PCB changed :

4

AEC Qualified :

yes

HTS Code :

8541.10.00.80
