GBJ1004
Or copy the link below:
- Mfr.Part #
- GBJ1004
- Manufacturer
- SMC Diode Solutions
- Package / Case
- 4-SIP, GBJ
- Datasheet
- Download
- Description
- BRIDGE RECT 1PHASE 400V 10A GBJ
- Stock
- 1
- In Stock ：
- 1
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- SMC Diode Solutions
- Product Category :
- Diodes - Bridge Rectifiers
- Qualification Status :
- Not Qualified
- Number of Pins :
- 4
- REACH SVHC :
- No SVHC
- Max Surge Current :
- 170A
- Peak Reflow Temperature (Cel) :
- 235
- Width :
- 4.8mm
- Output Current :
- 10A
- Base Part Number :
- GBJ1004
- Current Rating :
- 10A
- Number of Terminations :
- 4
- Mounting Type :
- Through Hole
- Voltage - Forward (Vf) (Max) @ If :
- 1.05V @ 5A
- Time@Peak Reflow Temperature-Max (s) :
- 10
- Current - Reverse Leakage @ Vr :
- 10μA @ 400V
- Package / Case :
- 4-SIP, GBJ
- Pin Count :
- 4
- Number of Elements :
- 1
- Reach Compliance Code :
- not_compliant
- Number of Phases :
- 1
- Additional Feature :
- UL RECOGNIZED
- Packaging :
- Tube
- Case Connection :
- Isolated
- Termination :
- Through Hole
- Reverse Voltage (DC) :
- 280V
- Capacitance :
- 55pF
- RoHS Status :
- Non-RoHS Compliant
- Forward Voltage :
- 1V
- JESD-609 Code :
- e0
- Length :
- 30.3mm
- Height :
- 24.5mm
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Operating Temperature :
- -65°C~150°C TJ
- Peak Reverse Current :
- 5μA
- Lead Free :
- Contains Lead
- Mount :
- Through Hole
- Diode Element Material :
- SILICON
- Voltage - Rated DC :
- 400V
- Peak Non-Repetitive Surge Current :
- 170A
- Diode Type :
- Single Phase
- Datasheets
- GBJ1004
Single Phase Bridge Rectifier Through Hole -65°C~150°C TJ 10μA @ 400V 1.05V @ 5A 4-Termination 1-Phase 4-SIP, GBJ Tube
GBJ1004 Overview
A total of 4 pins are present on it.Using the base part number GBJ1004, you can identify several related parts.Basically, it's an electronic component that comes in a 4-SIP, GBJ package.This device is mounted in the Through Hole position.Keeping it at -65°C~150°C TJ ensures its normal operation.A surge current should not exceed 170A and should be monitored.In order to power this device, there is a reverse voltage peak of 5μA.Due to its 10A output current, it offers maximum design flexibility.
GBJ1004 Features
4 pin count
4-SIP, GBJ package
operating at a temperature of -65°C~150°C TJ
peak reverse voltage of 5μA
a reverse voltage peak of 5μA
10A output current
GBJ1004 Applications
There are a lot of Diodes Incorporated
GBJ1004 applications of bridge rectifiers.
