DMF-04-S
Or copy the link below:
- Mfr.Part #
- DMF-04-S
- Manufacturer
- Adam Tech
- Package / Case
- Datasheet
- Download
- Description
- CONN HEADER VERT 4POS 4.2MM
- Stock
- 21,271
- In Stock ：
- 21,271
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Adam Tech
- Product Category :
- Headers, Male Pins
- Style :
- Board to Cable/Wire
- Reliability :
- COMMERCIAL
- Row Spacing - Mating :
- 0.165 (4.20mm)
- Contact Type :
- Male Pin
- Insulation Resistance :
- 1000000000Ohm
- Pitch - Mating :
- 0.165 4.20mm
- Number of Positions Loaded :
- All
- Factory Lead Time :
- 9 Weeks
- Insulation Height :
- 0.504 12.80mm
- Orientation :
- Straight
- Insulation Color :
- Natural
- Connector Type :
- Header
- Reference Standard :
- UL, CSA
- Number of Rows :
- 2
- Series :
- DMF
- Insulation Material :
- Polyamide (PA66), Nylon 6/6
- Packaging :
- Bulk
- Voltage - Rated :
- 250VAC
- Mixed Contacts :
- yes
- Shrouding :
- Shrouded - 4 Wall
- Fastening Type :
- Locking Ramp
- Number of Conductors :
- ONE
- Operating Temperature :
- -25°C~85°C
- Contact Finish - Mating :
- Tin
- Contact Length - Post :
- 0.134 3.40mm
- Termination :
- Solder
- Material Flammability Rating :
- UL94 V-2
- Current Rating (Amps) :
- 7A
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Mounting Type :
- Through Hole
- Contact Material :
- Brass
- Dielectric Withstanding Voltage :
- 1500VAC V
- Contact Shape :
- Square
- RoHS Status :
- ROHS3 Compliant
- Number of Positions :
- 4
- Datasheets
- DMF-04-S
DMF Series 2-Row Header Solder Brass Bulk Through Hole Tin Polyamide (PA66), Nylon 6/6 4-Position Board to Cable/Wire 0.504 12.80mm Height
DMF-04-S Overview
This product is packaged in a Header box.Through Hole indicates that the device is mounted.An Bulk case is utilized for packaging the product.The product is a part of the DMF Series.Operating temperature is set to -25°C~85°C.
DMF-04-S Features
DMF series
DMF-04-S Applications
There are a lot of Adam Tech
DMF-04-S Rectangular Connectors applications.
- Embedded systems
- Datacom
- Communication
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
