DBMM-17W2P
Or copy the link below:
- Mfr.Part #
- DBMM-17W2P
- Manufacturer
- ITT Cannon
- Package / Case
- Datasheet
- Download
- Description
- CONN D-SUB PLUG 17POS PNL MNT
- Stock
- 102
- In Stock ：
- 102
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- ITT Cannon
- Product Category :
- D-Sub Connector Assemblies
- Shell Finish :
- Cadmium
- Connector Style :
- D-Sub, Combo
- Product Type :
- D-Sub Connectors - Standard Density
- Packaging :
- Bulk
- Connector Type :
- Plug, Male Pins
- Durability :
- 500 Cycles
- Total Number of Contacts :
- 17
- Shell Material, Finish :
- Steel, Yellow Chromate Plated Zinc
- Wire Gauge :
- 8-26 AWG
- Material Flammability Rating :
- UL94 V-0
- Mounting Type :
- Panel Mount
- Contact Type :
- Signal and Coax or Power (Not Included)
- Feature :
- Shielded
- Reference Standard :
- UL
- Published :
- 2013
- DIN Conformance :
- No
- Insulation Material :
- POLYETHYLENE
- Series :
- 24308-Style, Combo D®, D*MM
- Mixed Contacts :
- yes
- Backset Spacing :
- --
- Termination Style :
- Solder Cup
- Manufacturer :
- ITT Cannon
- Ingress Protection :
- --
- Option :
- GENERAL PURPOSE
- Body Breadth :
- 0.494 inch
- Dielectric Material :
- Polycyclohexylenedimethylene Terephthalate (PCT)
- Housing Material :
- Polycyclohexylenedimethylene Terephthalate (PCT)
- Contact Finish Thickness :
- 50.0μin 1.27μm
- Mounting Angle :
- Straight
- Filter Feature :
- No
- Current Rating (Amps) :
- 7.5A
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Features :
- Shielded
- Gender :
- Male
- Wire Size (Max) :
- 8 AWG
- IEC Conformance :
- No
- Current Rating :
- 7.5A
- Pbfree Code :
- No
- Mounting Option 2 :
- LOCKING
- Number of Rows :
- 2
- Operating Temperature :
- -55°C~150°C
- Contact Gender :
- Pin (Male)
- Brand :
- ITT Cannon
- Product Status :
- Active
- Factory Lead Time :
- 21 Weeks
- RoHS :
- N
- Mounting Style :
- Through Hole
- Contact Design :
- PREASSEM CONN
- Empty Shell :
- yes
- Contact Form :
- Machined
- RoHS Status :
- Non-RoHS Compliant
- Voltage Rating :
- --
- MIL Conformance :
- No
- Shell Size, Connector Layout :
- 3 DB B - 17W2
- Type :
- PLUG
- Package :
- Bulk
- Number of Positions :
- 17 (15 + 2 Coax or Power)
- Contact Material :
- COPPER ALLOY
- UL Flammability Code :
- 94V-0
- Contact Resistance :
- 10MOhm
- Contact Finish :
- Gold
- Product Category :
- D-Sub Standard Connectors
- Color :
- Black
- Termination :
- Solder Cup
- Flange Feature :
- Housing/Shell (Unthreaded)
- Datasheets
- DBMM-17W2P
24308-Style, Combo D®, D*MM Series D-Sub, Combo Plug, Male Pins 17 (15 + 2 Coax or Power)-Position Male Signal and Coax or Power (Not Included) Solder Cup 3 DB B - 17W2 Panel Mount Copper Alloy Gold Steel, Yellow Chromate Plated Zinc
DBMM-17W2P Overview
Packaging is in the form of Plug, Male Pins.The mounting type of the device is Panel Mount.A Bulk case is used to package the product.A product of the 24308-Style, Combo D®, D*MM Series, it belongs to the range of products of that series.A number of features make the Shielded feature more powerful.-55°C~150°C Operating Temperature is the default operating temperature for the device.
DBMM-17W2P Features
24308-Style, Combo D®, D*MM series
DBMM-17W2P Applications
There are a lot of ITT Cannon, LLC
DBMM-17W2P D-Sub Connectors applications.
- Automotive Electronics
- Telecommunications
- Data Technology
- Blowers
- Control panels
- Electrical substations
- Energy efficient lighting (LED)
- LED municipal outdoor and street lighting
- All Electrical Machinery
- Refrigeration control
