CAT93C86L

Manufacturer :

Catalyst Semiconductor Inc.

Product Category :

Memory

Surface Mount :

No

Number of Words :

1024 words

Terminal Pitch :

2.54 mm

Manufacturer :

ON Semiconductor

Memory IC Type :

EEPROM

Technology :

CMOS

Data Retention Time-Min :

100

Number of Terminals :

8

Memory Width :

16

Terminal Form :

THROUGH-HOLE

Length :

9.36 mm

Memory Interface :

Microwire

Supply Voltage-Max (Vsup) :

6 V

Package Shape :

RECTANGULAR

Qualification Status :

Not Qualified

Number of Functions :

1

JESD-30 Code :

R-PDIP-T8

Parallel/Serial :

Serial

ECCN Code :

EAR99

Supply Voltage-Min (Vsup) :

2.5 V

Width :

7.62 mm

Serial Bus Type :

Microwire

Reach Compliance Code :

Compliant

Additional Feature :

1000000 PROGRAM/ERASE CYCLES; 100 YEAR DATA RETENTION

Seated Height-Max :

4.57 mm

Terminal Finish :

Tin (Sn)

Alternate Memory Width :

8

Memory Density :

16384 bit

Temperature Grade :

COMMERCIAL

Pin Count :

8

HTS Code :

8542.32.00.51

Factory Lead Time :

1 Week

Terminal Position :

Dual

Pbfree Code :

yes

Organization :

1KX16

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Product Status :

Active

Series :

*

Operating Mode :

SYNCHRONOUS

Package :

Bulk

JESD-609 Code :

e3
