6N134#100

Manufacturer :

Broadcom

Product Category :

Optoisolators - Logic Output

Direction :

Unidirectional

Common Mode Transient Immunity (Min) :

1kV/μs

Input Type :

DC

Current Transfer Ratio :

100 %

Packaging :

Tube

Forward Current :

20mA

Optoelectronic Device Type :

LOGIC IC OUTPUT OPTOCOUPLER

Hysteresis Ratio-Nom :

0.0125

Voltage - Forward (Vf) (Typ) :

1.55V

Mounting Type :

Surface Mount

Propagation Delay tpLH / tpHL (Max) :

100ns, 100ns

Turn On Delay Time :

140 ns

Mount :

Surface Mount

Data Rate :

10MBd

Inputs - Side 1/Side 2 :

2/0

Published :

2015

Output Current per Channel :

25mA

Voltage - Supply :

4.5V~5.5V

Rise / Fall Time (Typ) :

35ns 35ns

Number of Elements :

2

Output Type :

Open Collector, Schottky Clamped

Terminal Finish :

Gold (Au)

Additional Feature :

HIGH RELIABILITY, OPEN COLLECTOR, TTL COMPATIBLE

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Package / Case :

16-SMD, Butt Joint

Radiation Hardening :

yes

Max Output Current :

25mA

HTS Code :

8541.40.80.00

Response Time :

3.5e-8 ns

Supply Voltage :

5V

Lead Free :

Exempt

Operating Temperature :

-55°C~125°C

Factory Lead Time :

12 Weeks

ECCN Code :

EAR99

RoHS Status :

ROHS3 Compliant

Propagation Delay :

100 ns

Rise Time :

90ns

JESD-609 Code :

e4

Fall Time (Typ) :

40 ns

Number of Channels :

2

Voltage - Isolation :

1500VDC

Max Power Dissipation :

200mW
