583680-1

Share

Or copy the link below:

Mfr.Part #
583680-1
Manufacturer
TE Connectivity AMP Connectors
Package / Case
Datasheet
Download
Description
CONN CARDEDGE HSG 30POS .156 BLK
Stock
7,145
In Stock :
7,145

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
TE Connectivity AMP Connectors
Product Category :
Card Edge Connector Housings
Reliability :
COMMERCIAL
ELV :
Compliant
Contact Current Rating :
5A
Card Thickness :
0.055 ~ 0.070 1.40mm ~ 1.78mm
Packaging :
Bulk
Flange Feature :
Top Mount Opening, Unthreaded, 0.128 (3.25mm) Dia
Orientation :
Straight
IEC Conformance :
No
Feature :
Flange
PCB Thickness :
1.778mm
Pbfree Code :
yes
MIL Conformance :
No
Min Operating Temperature :
-65°C
Card Type :
Non Specified - Dual Edge
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Pitch :
0.156 3.96mm
ECCN Code :
EAR99
HTS Code :
8536.69.40.40
Current Rating :
5A
DIN Conformance :
No
Preloaded :
No
Body Breadth :
0.35 inch
Total Number of Contacts :
30
Additional Feature :
POLARIZED
Option :
GENERAL PURPOSE
Mixed Contacts :
No
RoHS Status :
RoHS Compliant
Note :
Contacts Not Included
Published :
1997
Insertion Force-Max :
4.448 N
Number of Rows :
2
Termination Type :
Solder
Color :
Black
Withdrawl Force-Min :
.556 N
Lifecycle Status :
ACTIVE (Last Updated: 5 days ago)
Contact Pattern :
RECTANGULAR
Rated Current (Signal) :
5A
Height :
17.78mm
Connector Type :
PLUG
Max Operating Temperature :
125°C
Factory Lead Time :
13 Weeks
Mount :
Panel
Number of Positions :
30
Length :
81.0006mm
Series :
Amp-Leaf
Housing Material :
Polyester
Body Depth :
0.7 inch
Contact Gender :
FEMALE
Mounting Type :
Panel Mount
Lead Free :
Not Applicable
Insulation Resistance :
5GOhm
Reference Standard :
UL, CSA
Filter Feature :
No
Datasheets
583680-1
Introducing Card Edge Connector Housings TE Connectivity AMP Connectors 583680-1 from Chip IC,where excellence meets affordability. This product stands out with its Mounting Type:Panel Mount, 583680-1 pinout, 583680-1 datasheet PDF, 583680-1 amp .Beyond Card Edge Connector Housings TE Connectivity AMP Connectors 583680-1 ,we also offer 1703129-1, 583861-5, 1-583717-1, Our vast inventory has you covered. Contact us now for immediate solutions.

TE Connectivity AMP Connectors 583680-1
