Mfr.Part #
5390402-3
Manufacturer
TE Connectivity AMP Connectors
Package / Case
Datasheet
Download
Description
CONN SKT DIMM 184POS PCB
Stock
25,594
In Stock :
25,594

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
TE Connectivity AMP Connectors
Product Category :
Inline Module Sockets
Filter Feature :
No
Mounting Option 2 :
LOCKING
Row Spacing :
1.6002 mm
Circuit Application :
Signal
Lead Length :
3.18 mm
Pbfree Code :
yes
Memory Type :
DDR, DDR SDRAM, SDRAM
Housing Color :
Black
Additional Feature :
LOW PROFILE
Body Depth :
0.656 inch
Voltage Rating :
2.5 V
Total Number of Contacts :
184
IEC Conformance :
No
Length :
140.98 mm
Number of Positions :
184
Depth :
28.18 mm
Termination :
Solder, Through Hole
MIL Conformance :
No
Contact Finish Termination :
Tin (Sn) - with Nickel (Ni) barrier
JESD-609 Code :
e3
Mounting Type :
BOARD
Polarization Key :
POLARIZED HOUSING
Connector Type :
CARD EDGE CONNECTOR
PCB Contact Row Spacing :
1.6002 mm
Brand Name :
AMP
Mount :
Through Hole
Option :
GENERAL PURPOSE
Mixed Contacts :
No
Contact Current Rating :
500 mA
Terminal Length :
0.125 inch
Max Operating Temperature :
185 °C
Terminal Pitch :
1.27 mm
Housing Material :
Nylon
Contact Plating :
Gold
PCB Contact Pattern :
STAGGERED
Min Operating Temperature :
-67 °C
Radiation Hardening :
No
Number of Contacts :
184
Reference Standard :
UL
Body Breadth :
0.46 inch
Insulation Material :
Nylon
Flammability Rating :
UL94 V-0
Contact Gender :
FEMALE
Number Of PCB Rows :
4
Board Mounting Option :
PEG
Termination Type :
Solder
Reach Compliance Code :
Compliant
Reliability :
COMMERCIAL
Hole Diameter :
2.25 mm
Mounting Style :
25 DEGREE
Number of Rows :
2
RoHS :
Compliant
Mounting Option 1 :
LATCH and EJECT
Pitch :
1.27 mm
Contact Style :
BELLOWED TYPE
DIN Conformance :
No
Contact Material :
Phosphor Bronze
Plating Thickness :
30u inch
Body/Shell Style :
Socket
Datasheets
5390402-3
Introducing Inline Module Sockets TE Connectivity AMP Connectors 5390402-3 from Chip IC,where excellence meets affordability. This product stands out with its Mounting Type:BOARD, 5390402-3 pinout, 5390402-3 datasheet PDF, 5390402-3 amp .Beyond Inline Module Sockets TE Connectivity AMP Connectors 5390402-3 ,we also offer 1565917-4, MM80-204B1-1R, 1473005-4, Our vast inventory has you covered. Contact us now for immediate solutions.
