Manufacturer :

Schott Corporation

Product Category :

Pulse Transformers

Actuator Color :

Green

Operating Temperature (Min) :

-25°C

Moisture Sensitivity Level (MSL) :

Not Applicable

Contact Current(DC)-Max :

0.2A

Published :

2001

Packaging :

Tape and Reel (TR)

PCB Hole Count :

6

Inductance :

1.2mH

Switch Action :

LATCHED

Length - Termination :

0.134 inch

Additional Feature :

RECT BUTTON W/ LEGEND,GRN LED

Termination Type :

Solder

Transformer Type :

T1/E1 (Quad)

Insulation Resistance :

10000000000Ohm

Terminal Material :

Brass

Center Contact Plating :

Silver

Actuator Material :

Polycarbonate

ECCN Code :

EAR99

Actuator Length :

0.492 inch

Contact Voltage(DC)-Max :

50V

JESD-609 Code :

e3

Contact (DC) Max Rating R Load :

0.2A@50VDC

Actuator Type :

Pushbutton

Mount :

Surface Mount

Contact Resistance :

0.025mOhm

Contact (AC) Max Rating R Load :

0.2A@60VAC

Terminal Finish :

Matte Tin (Sn)

Contact Voltage(AC)-Max :

60V

Package / Case :

SMD/SMT

Body Height :

12.0904mm

Switch Type :

PUSHBUTTON SWITCH

Turns Ratio - Primary:Secondary :

1:1.36CT

Height Seated (Max) :

0.290 7.37mm

Mounting Type :

Surface Mount

Illumination :

LED

Electrical Life :

100000 Cycle(s)

Switch Function :

DPST

Operating Temperature (Max) :

60°C

Size / Dimension :

1.000Lx0.300W 25.40mmx7.62mm

Contact Function :

Off-On

Pbfree Code :

yes

End Contact Plating :

Silver

Contact Current(AC)-Max :

0.2A

Center Contact Material :

Brass

RoHS Status :

Non-RoHS Compliant

Insulation Material :

Polysulfone

End Contact Material :

Brass
