2273023-1

Manufacturer :

Molex

Product Category :

Unclassified

Wire Gauge :

22(AWG)

Coding :

A

RoHS :

Details

Minimum Bend Radius :

43 mm

IP Rating :

IP65, IP67

Length :

1.5m

Packaging :

Box

Brand Name :

TE Connectivity

Product Type :

Sensor Cables / Actuator Cables

Connector Type B :

Not Included

Cable Type :

Sensor

Gender :

Receptacle

Subcategory :

Cable Assemblies

Factory Lead Time :

16 Weeks, 5 Days

Product Category :

Sensor Cables / Actuator Cables

Wire Size :

22 AWG

Connector Type :

CIRCULAR CONNECTOR

Standards Met :

CSA, ELV Compliant, EN 60529, RoHS Compliant, UL

Connector Type A :

M12 Circular

Voltage Rating :

250 V ac/dc

Reach Compliance Code :

Compliant

Outer Diameter :

4.3mm

Current Rating (Max) :

4/Contact(A)

Maximum Operating Temperature :

+80°C

Color :

Blue/Black

Voltage Rating Max :

250VDC/250VAC

Wire Gauge - AWG :

22 AWG

Jacket Material :

Rigid Polyurethane (PUR)

Operating Temperature Range :

-40 → +80 °C

Brand :

TE Connectivity

Operating Temp Range :

-40C to 80C

Current Rating :

4 A

Operating Temperature :

-25 to 85 °C

Series :

M12

Cable Length :

1.5 m

Insulation Material :

PP

Minimum Operating Temperature :

-40°C

Number of Cores :

3
