Mfr.Part #
2058703-1
Manufacturer
TE Connectivity AMP Connectors
Package / Case
Datasheet
Download
Description
CONN SSL RCPT & BLADE 2POS 4MM
Stock
5,473
In Stock :
5,473

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
TE Connectivity AMP Connectors
Product Category :
Solid State Lighting Connector Assemblies
High Temperature Compatible :
yes
Plating :
Tin
Current Rating (Amps) :
6A
ELV :
Compliant
Termination :
Solder
PCB Mount Alignment :
Without
Voltage - Rated AC :
125V
Height :
3.9mm
Max Operating Temperature :
105°C
Gender :
Receptacle
Factory Lead Time :
15 Weeks
Voltage - Rated :
125V
Lifecycle Status :
ACTIVE (Last Updated: 1 day ago)
Current Rating :
6A
PCB Mounting Orientation :
RIGHT ANGLE
Pitch :
0.157 4.00mm
Make First / Break Last :
No
Stackable :
No
Depth :
19.75mm
Housing Color :
Natural
REACH SVHC :
Unknown
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Mating Alignment :
Without
Style :
Board to Board
Max Voltage Rating (DC) :
125.125kV
Contact Gender :
Hermaphroditic
Color :
Natural
Orientation :
RIGHT ANGLE
Sealable :
No
Contact Current Rating :
6A
Connector Type :
Blade and Receptacle, Hermaphroditic
PCB Thickness :
1.57mm
Length :
8.7mm
PCB Mount Retention :
Without
RoHS Status :
RoHS Compliant
Mounting Type :
Board Edge, Surface Mount, Right Angle
Housing Material :
Liquid Crystal Polymer (LCP)
Max Voltage Rating (AC) :
125V
Material :
Thermoplastic
Number of Pins :
2
Contact Finish :
Tin
Operating Supply Voltage :
125V
Flammability Rating :
UL94 V-0
Number of Contacts :
2
Operating Temperature :
-40°C~105°C
Number of Rows :
1
Contact Material :
COPPER ALLOY
Packaging :
Cut Tape (CT)
Published :
2009
Lead Free :
Lead Free
Number of Positions :
2
Mount :
Surface Mount
Fastening Type :
Locking Ramp
Approval Agency :
CSA
Min Operating Temperature :
-40°C
Contact Plating :
Tin
Datasheets
2058703-1
Introducing Solid State Lighting Connector Assemblies TE Connectivity AMP Connectors 2058703-1 from Chip IC,where excellence meets affordability. This product stands out with its Mounting Type:Board Edge, Surface Mount, Right Angle, Number of Pins:2, Operating Temperature:-40°C~105°C, 2058703-1 pinout, 2058703-1 datasheet PDF, 2058703-1 amp .Beyond Solid State Lighting Connector Assemblies TE Connectivity AMP Connectors 2058703-1 ,we also offer 5034710200, 2834006-2, DF59-2P-2C, Our vast inventory has you covered. Contact us now for immediate solutions.
